Интеллектуальное твердотельное реле QWIFM 60A DC/AC
- Категория: Industrial Controls >>>
- Поставщик: Shanghai,Nature,Beyond,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 9.8 $* | 9.40 $* |
| Jul-18-2025 | 7.79 $* | 7.61 $* |
| Jun-18-2025 | 9.22 $* | 9.52 $* |
| May-18-2025 | 9.47 $* | 9.61 $* |
| Apr-18-2025 | 7.64 $* | 7.61 $* |
| Mar-18-2025 | 9.58 $* | 9.62 $* |
| Feb-18-2025 | 8.8 $* | 8.56 $* |
| Jan-18-2025 | 8.48 $* | 8.83 $* |
Характеристики
Specification
| Model | ISSR-10DA | ISSR-25DA | ISSR-40DA | ISSR-50DA | ISSR-60DA | ISSR-70DA | ISSR-80DA | ISSR-90DA | ISSR-100DA | ISSR-120DA |
| Load Current | 10A | 25A | 40A | 50A | 60A | 70A | 80A | 90A | 100A | 120A |
| Load Voltage | 24-600VAC | |||||||||
| Control Voltage | 2.3-48VDC | |||||||||
| Control Current | 3-20mADC | |||||||||
| On Voltage | ≤1.5VAC | |||||||||
| Off-state Leakage Current | ≤4mA | |||||||||
| Time Off | ≤10ms | |||||||||
| Dielectric Strength | 2500VAC | |||||||||
| Insulation Resistance | 100MΩ/500VDC | |||||||||
| Ambient Temperature | -25℃~+75℃ | |||||||||
| Mounting Methods | M4 fixed Bolt | |||||||||
| The work instructions | Double LED(Green:Working,Red:Breakdown) | |||||||||
| Weight | 65g | |||||||||
Product Details
FAQ
1,Are you trading company or manufacturer?
We are manufacturer,specialize in producing proximity sensor, photoelectric sensor,switching power supply, SSR, and rotary encoder for 22 years.
2,What's the minimum order quantity?
1 piece, and we can offer free sample for testing.
3,What's your price?
We have economic and high-end products, can meet different customers' requirements.Meanwhile, we can offer much better price in large quantity.
4,When will you ship my order?
1 day shipping guarantee for stock item and 2-3 weeks for non-stock items.
5,What's your shipping terms?
We can provide courier(DHL, FEDEX,UPS,TNT etc...)service, air freight, sea freight(-FOB,C&F, CIF,DDP,DDU etc...) service.
6,How can you guarantee the product quality?
We ensure all products 100% tested before departure.Our products have passed CE,ISO9001:2000, ccC, and CB certification.
7,Do you accept OEM?
Yes.We can special customized waterproof lP68/IP69 sensor, and offer cable length perto customers" request.
8,How can I make an order?
Send inquiry→Tell us your requirements→Our sales will contact you within 2 hours.
