AL проводник XLPE изолированный ПВХ оболочка верхний кабель через дерево

Описание и отзывы

Трекер стоимости

Характеристики

Applications:

Covered line wire is used primarily for 600v secondary overhead power distribution lines. It is not an electrically insulated conductor and often considered a bare conductor.



Construction:

The aluminum conductors are 1350-H19 aluminum, 6201-T81 Aluminum Alloy, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HDPE) or cross-linked polyethylene(XLPE)



Standards:

ASTM B-230 - Aluminum 1350-H19 Wire for Electrical Purposes ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR). ASTM B-1248 - Polyethylene Plastics Molding and Extrusion Materials. ASTM C-8.35 - Specifications for Weather-Resistant Polyethylene-Covered Wire and Cable. ICEAS-61-402



Warm Tips	Please kindly confirm below information when send inquiry to us	Send  Inquiry
	1.Quantity?
	2. FOB or CIF price?(if CIF,tell us your destination port)
	3.What's your application?
	4.Are you distributor or an end user?
	5.When do you expect the delivery time?
	6.Your whatsapp/Skype/Wechat ID and email address?

Type: Covered Line Wire, Duplex Service Drop, Triplex Service Drop, Quadruplex Service Drop

a. Covered Line Wire Applications: is used primarily for 600v secondary overhead power distribution lines. It is not an electrically insulated conductor and often considered a bare conductor.



b. Duplex Service Drop Applications:To supply 120 volt aerial service for temporary service at construction sites,outdoor or street lighting . For service at 600 volts or lower at a conductor temperature of 75 maximum.



c. Triplex Service Drop Applications: To supply power from the ulility`s lines to the consumer`s weatherhead. For service at 600 volts or less(phase to phase ) at a conductor temperature of 75 maximum for PE insulation or 90 maximum for XLPE insulation .



d. Quadruplex Service Drop Applications: Used to supply 3 phase power , usually from a pole-mounted transformer to the use`s servic head where connection to the service entance cable is made . To be used at voltages of 600 volts or less phase to phase and at conductor temperature not to exceed 75 for PE insulated conductors or 90 for XLPE insulated conductors.





Bare conductor

 Aluminum conductors (AAC  AAAC  ACSR  ACAR /AW  ACSS  ACSS/TW)

Aluminum clad steel wire (Alumoweld), Galvanized steel wire

Catenary/Contact wire for electrical railway



Insulated cables

Cover line wire-Aluminum conductor

Aerial bounded cable (service drop)

Aerial bounded cable (service drop)

AA8000 series Aluminum alloy cable







Henan Tong-Da Cable Co.,LtdHenan Tong-Da Cable Co.,Ltd founded in 1987, covers an area of 360,000 square meters.

The annual production capacity of conductors and power cables is more than 100,000 tons. On March 3, 2011, Tong-Da became a public company listed on the Shenzhen Stock Exchange.



Meanwhile we can produce according to customers' requirements and specifications. We have obtained certificates of ISO9001, ISO14001, China's Electrical Product Safety Certification, State Economic and Trade Commission Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.



Through years of unremitting effort and endeavors, we have achieved sound reputation and widely compliments from clients all over the world by superior quality, reasonable price and sincere after-sale services.

















Q1. Are you a manufacturer?

Yes, we are a manufacturer own factory with almost 30 years experiences.



Q2. What are your main products?

Main products including: ACSR, AAC, AAAC ,ACAR,ACSS,ACSS/TW,ACCC,ACSR/AW,ACS ,GSW, Aerial Bundled Cable(Low/Medium Voltage),Power Cable,Copper Alloy Wire for Electrical Railway System



Q3. Which countries and regions have your products been exported to ?

Asia, South America, North America, Europe, Africa, Oceania,including: Peru,Colombia, Chile,Korea, America, Philippines, Vietnam,Singapore, Australia,Dominica,Kenya,Poland,Pakistan,Rwanda,Brazil,Myanmar,Zambia, Congo,Ecuador,Lesotho,Bolivia,Thailand ,Germany,Angola,Yemen,India,Netherlands,Benin,Maldives,Canada,Honduras,Albania,Burundi,Paraguay , Sri Lanka,New Zealand,Bahrain,Costa Rica,Trinidad and Tobago,Guyana, Nicaragua,Mongolia,Haiti,Ghana,Macedonia etc.



Q4. Is the quality of your products guaranteed?

Yes,the quality of our products is highly guaranteed. The products are ISO 9001 ,ISO 14001,OHSAS 18001 certificated. Our workshops are equipped with advanced production and inspection equipment and the products strictly according to international standards or customers' requirements. We do 100% inspection for every batch of semi-finished and finished products.



Q5. What’s the package of products ?

The package is usually wooden drums ,steel drums,steel-wooden drums or according to customers’ requirement.



Q6. How can I get samples?

Please notify the detailed information of sample you need. If we don't have the exact model, please consider whether the similar model is OK for you. we provide the free samples for inspection while freight is charged.



Q7. What is our payment terms ?

We can accept the following payment terms: T/T, L/C, O/A
