Китай оптовая продажа печатная Фотополимерная
- Категория: Печатная пластина >>>
- Поставщик: Guilin,Zhuonuo,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.27 $* | 0.15 $* |
| Aug-16-2025 | 0.67 $* | 0.42 $* |
| Jul-16-2025 | 0.79 $* | 0.66 $* |
| Jun-16-2025 | 0.40 $* | 0.95 $* |
| May-16-2025 | 0.51 $* | 0.19 $* |
| Apr-16-2025 | 0.2 $* | 0.6 $* |
| Mar-16-2025 | 0.6 $* | 0.32 $* |
| Feb-16-2025 | 0.67 $* | 0.15 $* |
| Jan-16-2025 | 0.95 $* | 0.0 $* |
Характеристики
Clichés Steel Material Comparison Chart
Steel Type | GCr15 | 2510(01,CrWMn) | SKD11(9Cr12MoV) |
Clich é Marks | HR | EN | D2 |
Rust Resistance Ability | AAA | AAAA | AAAAA |
Printing Life | √√ | √√√√ | √√√√√ |
Clichés Production Parameters
Heattreatment Hardness | HRC 63+/-1 |
Clichés Surface Finish Roughness | Black Surface---Ra0.1μm Bright Surface---Ra0.01μm Mirror Surface---Ra0.001μm |
Clichés Surface Parallel | For Open Type Pad Printers……500:0.05mm For Cup Type Pad Printers……500:0.005mm |
Clichés Machining Thickness | Common thickness: 9.8-10.2mm Special thickness: 8mm,9mm,12mm, 13mm, 15mm Other thickness can be customized. |
Clichés Plates Common Size | 70x140mm,75x100mm,75x150mm,75x200mm… 100x100mm,100x150mm,100x200mm,100x215mm, 100x250mm… 150x150mm,150x300mm,150x350mm… 200x200mm,200x500mm,200x550mm… Other thickness can be customized. |
Clichés Machining Size | Any special size clichés can be made to order. |
