Oriemac 60ton ZTC600V532 хорошая распродажа грузовых кранов в

Oriemac 60ton ZTC600V532 хорошая распродажа грузовых кранов в

Категория: Truck Cranes >>>
Поставщик: Oriemac,Machinery,&,Equipment,(Shanghai),Co.,Ltd.

Цена:170 000,00 $ - 180 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	202300.10 $*	212415.32 $*
Aug-20-2025	200600.96 $*	210630.51 $*
Jul-20-2025	168300.20 $*	176715.58 $*
Jun-20-2025	197200.22 $*	207060.65 $*
May-20-2025	171700.85 $*	180285.18 $*
Apr-20-2025	193800.6 $*	203490.63 $*
Mar-20-2025	192100.92 $*	201705.68 $*
Feb-20-2025	190400.28 $*	199920.39 $*
Jan-20-2025	188700.86 $*	198135.93 $*

Характеристики

Oriemac 60ton ZTC600V532 Good Sale Truck Crane In Bangladesh

web

contact

Contact Me: Peggy

Mobile / Whatsapp / Wechat: +86 13917864319
Email: peggy at oriemac.com
Facebook: http://www.facebook.com/profile.php?id=100025041697080
Web: http://www.oriemac.com

Product Description

• Continuously overall promotion makes our lifting capacity of crane be improved once and once again.
• Jib length 8.0m,Main boom length(10.6 – 40.0m).
• Optimized central slewing position increases the lifting capacity of the crane over rear.
• Large outrigger span improves the working stability of the crane greatly,
• Adopt internationally advanced structure analysis and calculation methods to develop the lifting capacity of crane deeply.
• Leading boom manufacturing process in trade.

Specs Chart

Item	Unit	Value
Working performance	Max. rated lifting capacity		kg	25000
	Max. load moment of basic boom		kN.m	950
	Max. load moment of main boom(fully extended)		kN.m	525
	Max. lifting height of main boom		m	38.7
	Max. lifting height of jib		m	46.58
Working speeds	Max. hoist rope speed(Main winch)		m/min	135
	Max. hoist rope speed(Auxiliary winch)		m/min	100
	Boom derricking up time		s	40
	Boom derricking up time		s	120
	Slewing speed		r/min	2.6
Driving parameters	Max. driving speed		km/h	72
	Max. gradeability		%	34
	Min. turning diameter		m	≤20
	Min. ground clearance		mm	235
	Limits for exhaust pollutants and smoke			Comply with related standards
	Oil consumption per hundred kilometers		L	38
Mass	Dead weight in driving condition		kg	29400
	Complete vehicle kerb mass		kg	29270
	Front axle load		kg	6370
	Rear axle load		kg	22900
Dimensions	Overall dimensions(L×W×H)		mm	12510×2500×3455
	Outrigger spread(L)		m	5.15
	Outrigger spread(W)		m	6.1
	Main boom length		m	10.3-38.5
	Boom angle		°	-2-80
	jib length		m	8
	Offset		°	0,30
Chassis	Model			ZLJ5323JQZ
	Type			II
	Engine	Model	kw/r/min	WP6.240
		Rated power	n.m/r/min	176/2300
		Max. output torque		900/1400 - 1600
	Manufacturer			Heavy Industry Science and Technology Co., Ltd.
