Лидер продаж 2021 высокоэффективные полуэлементные солнечные панели 320 Вт 330 340 для проектов

Описание и отзывы

Трекер стоимости

Характеристики







ELECTRICAL DATA(STC)
Peak Power Watts-Pmax(Wp)	320W	325W	330W	335W	340W
Power Output Tolerance-P MAX (W)	0~+5W
Maximum Power Voltage-V MPP (V)	33.6	33.8	34.1	34.4	34.6
Maximum Power Current-l MPP (A)	9.52	9.61	9.67	9.73	9.82
Open Circuit Voltage-V OC (V)	41.3	41.5	41.9	42.3	42.5
Short Circuit Current-l SC (A)	10.19	10.28	10.35	10.4	10.51
Module Efficiencyηm (%)	18.96	19.26	19.55	19.85	20.15
STC	Irradiance 1000w/m2,module temperature 25℃,air mass 1.5







TEMPERATURE RATINGS
Nominal Operating Cell Temperature (NOCT)	44℃(±2℃)
Temperature Coefficient of PMAX	- 0.39%/℃
Temperature Coefficient of VOC	- 0.29%/℃
Temperature Coefficient of ISC	0.05%/℃





MECHANICAL DATA
Solar cells	Monocrystalline 158.75×79.375mm
Cell orientation	120cells (6×20)
Module dimensions	1684×1002×35mm
Weight	18kgs
Glass	3.2mm (0.13 inches), HighTransmission, AR Coated Tempered Glass
Frame	Silver anodized alunnium alloy
Backsheet	Silver
J-Box	IP67 rated
Cables	Photovoltaic Technology cable 4.0mm2 (0.006 inches2), 300mm (11.82 inches)
Connector	MC4 or MC4 Compatible























Payment
Payment Term	T/T	EXW	30% T/T advance,paid the balance before shipment
		FOB
		CFR(C&F)	30% T/T advance,paid the balance against copy of B/L
		CIF
	L/C	L/C amount above 50,000usd,we can accept L/C at sight
	West Union	Amount lower than 5000usd
	West Union
Delivery time	7-10 working days after receiving payment for one container



          FAQ



1. Q: Do you have your own factory?

     A: Yes, we do. Our loctation is in Tangshan city, Hebei province.

2. Q: How can I visit your factory?

     A: Please let us konw bofore you go there. We will arrange time to pick you up and show you around.

3. Q: Do you provide free sample?

     A: Usually we do not provide free sample.

4. Q: Could you print our company LOGO on the nameplate and package?

     A: Yes, we can.

5. Q: Do you accept custom design on size?

     A: Yes, if the size is feasible.

6. Q: Do you have solar project engineer who can guide me to install system?

   A: Yes, we have a professional engineer team. They can teach you how to install a solar system.

PS:Our factory can produce all kinds of solar panels and solar moudles according to customers' needs.
