Полностью автоматическая машина для резки силиконовых вафель на солнечных
- Категория: Лазерное скрайбирование >>>
- Поставщик: Wuhan,Sunic,Photoelectricity,Equipment,Manufacture,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.71 $* | 0.61 $* |
| Aug-16-2025 | 0.3 $* | 0.22 $* |
| Jul-16-2025 | 0.88 $* | 0.69 $* |
| Jun-16-2025 | 0.6 $* | 0.35 $* |
| May-16-2025 | 0.77 $* | 0.64 $* |
| Apr-16-2025 | 0.16 $* | 0.67 $* |
| Mar-16-2025 | 0.69 $* | 0.30 $* |
| Feb-16-2025 | 0.61 $* | 0.49 $* |
| Jan-16-2025 | 0.39 $* | 0.74 $* |
Характеристики
Product Description
laser scribing machine,fiber laser scribing machine,solar cell cutting machine,solar cell laser scribing machine, solar cell
scriber ,silicon wafer fiber laser scribing machine.
1.New prodcut solar cell scriber laser scribing machine of sunic laser.New designed machinery structure make the whole machine
more concise and convenient for operation.Re-write partial source codes of solar cell scriber laser scribing machine software to
ensure more and more stable and faster run.
2.High quality laser scribing machine / solar cell scriber .Imported fiber laser to display better laser beam quality(standard
base model),thinner cutting slit and smoother cutting edge.
3.The PV cells laser cutting/solar cell scriber's independent research.International standard moduler design,needed no
mainternace,can keep uninterrupted continuous operation of new solar cell scriber laser scribing machine.
4.Convenient operation is intergrated into machine for smaller equipment volume and more convenient operation.The control software
of solar cell scriber laser scribing machine is designed specially for fiber laser scirbing mahine by our own company Sunic Laser.
5.T-style duplex worktable of fiber laser scribing machine runs alternately,to promote the working efficiency.And the max speed of
laser scribing machine can reach 20mm/s.
scriber ,silicon wafer fiber laser scribing machine.
1.New prodcut solar cell scriber laser scribing machine of sunic laser.New designed machinery structure make the whole machine
more concise and convenient for operation.Re-write partial source codes of solar cell scriber laser scribing machine software to
ensure more and more stable and faster run.
2.High quality laser scribing machine / solar cell scriber .Imported fiber laser to display better laser beam quality(standard
base model),thinner cutting slit and smoother cutting edge.
3.The PV cells laser cutting/solar cell scriber's independent research.International standard moduler design,needed no
mainternace,can keep uninterrupted continuous operation of new solar cell scriber laser scribing machine.
4.Convenient operation is intergrated into machine for smaller equipment volume and more convenient operation.The control software
of solar cell scriber laser scribing machine is designed specially for fiber laser scirbing mahine by our own company Sunic Laser.
5.T-style duplex worktable of fiber laser scribing machine runs alternately,to promote the working efficiency.And the max speed of
laser scribing machine can reach 20mm/s.
Technical Parameters
Technical Index | Technical Parameter |
Type specification | SFS20 |
Wave lengh of laser | 1064nm |
Laser power | 20W |
Laser repetition frequency | 20Khz-100khz |
Max scriber speed | 200mm/s |
Scriber line width | ±10μm |
Scribing line width | <30μm |
Work platform size | 350x350mm |
Power supply | 380V(220V)/50HZ/1.5KVA (customized) |
Cooling ways | Forced-air cooling |
Working temperature | 0-35℃ |
Working humidity | 5-95% |
Package | Standard Wood Package for Export, Customs Suffocating Free |
Work platform | The adsorption of double gas warehouse vacuum,the T-model platform is double position works in turn |
