Провод для бытового использования изолированный электрический провод из пвх кабель 1015 18AWG высокотемпературный нагревательный

Описание и отзывы

Трекер стоимости

Характеристики

this Link price is for PVC 1015 of 18awg wire, if you want other wires and size, kindly send us an inquiry

Product Name	Household Use Wire PVC Insulated  Electrical Wire Cable 1015 18AWG High Temperature 105deg Heating Wire.
Cable Length Per Roll	610m/roll
Use	Fine tuning ,LED drive power ,Transformer,fan electronic speed switch
Awg	10awg - 24awg
Conductor Specification	34/0.18TS;34/0.16TS;34/0.14TS for 18awg
Insulated Material	PVC
Features	Rated temperature: 105 ° C, rated voltage: 600V, must pass UL VW-1 and CSA Ft1 vertical flame resistance test, uniform insulation thickness
Color	Black red Pink Green White Blue Or Customized Color
OEM	Available
Material for Conductor	,Tinned Copper,
Sample	2 Meter Free Sample,Shipping cost on customer side,



Each Size Specification For PVC 1015 Electric Wire

Conductor			Insulation		Unit length
Size	Construction	Diameter	Nominal Thickness	Over Diameter	(M)(Ft)
(AWG)	(No./mm)	(mm)	(mm)	(mm)	Meter
24	1/0.511	0.5	0.8	2.2	610
22	1/0.643	0.64	0.8	2.4	610
20	1/0.813	0.81	0.8	2.6	610
18	11/1.024	1.02	0.81	2.8	610
26	7/0.16	0.49	0.76	2	610
24	11/0.16	0.61	0.8	2.2	610
22	17/0.16	0.76	0.82	2.4	610
20	21/0.178	0.94	0.83	2.6	610
18	34/0.178	1.2	0.8	2.8	610
16	26/0.254	1.5	0.8	3.1	305
14	41/0.254	1.88	0.81	3.5	305
12	65/0.254	2.37	0.77	3.9	305
10	105/0.254	3.01	1.05	5.1	305

If you have any other questions, please click here to " send an inquiry "

1. Q: Are you trading company or manufacturer ?

A: We are factory. We always leads the new trend of modern society, actively adopts new materials and new technologies, and continues to write a new page of glorious history.



2. Q: How does your factory do regarding quality control?

A: "Quality is our culture." We always attach great importance to quality controlling from the very beginning to the very end..



3. Q: Do you provide samples ? Is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay shipping charge.



4. Q: How long is your delivery time?

A: Normally  it is 10-20 days, it will depend on quantity.



5. Q: What is your terms of payment ?

A: Payment 30% T/T in advance, balance before shippment. we can accept Trade Assurance/Paypal/Western Union etc.



6. Q: After sales service:

A: All of our products are made by top quality ,we will check the quality before deliver to you. If there any problem on quality .We will solve the problem for you in the first time, and will come up with the most suitable solution to solve the after-sales problem.



If you have any other questions, please click here to '' send an inquiry ''
