Полиуретановая пенопластовая изоляция для украшения стен зернистая доска с 3d

Описание и отзывы

Трекер стоимости

Характеристики

polyurethane foam insulation wall decoration 3d groove grain board

The polyurethane cold room panel is composed of two galvanized stee sheets and rigid polyurethane foam in the middle. Because the polyurethane cold room panel has several outstanding advantages, such as thermal insulation, waterproof, light weight and fast installation, It has been widely used as the building material of cold storages, cool rooms, clean rooms, free-dust workshops and exterior walls in cold places.
At present, BRD polyurethane cold room panel has five different thickness: 50mm, 75mm, 100mm, 150mm, 200mm.

Panel Material	Metal
Brand	BRD
Place of Origin	China
Density	40 – 42 kg/m3
Length	Customized as long as it can be transported away
Effective Width	1,000mm
Core Thickness	50mm, 75mm, 100mm
Thickness of Surface Metal	0.4 - 0.7mm
Features	Sound proof, fire proof, water proof
Certificates	CE, ISO14001, ISO9001
Surface Appearance	Small wave, flat, embossment, big rib, etc.
Color	Customized
Fire Proof Rate	B



BRD PU Panel consists of three layers:
The top material is special aluminum-zinc coated metal board, the core material is rigid high-density Polyurethane foaming with fire-retardant treatment, and the back side is foil protective layer.
Generally speaking, there are three kinds of polyurethane panels:

(1)pu sandwich wall panel

(2)pu sandwich roof panel

(3)pu sandwich panel used for cold room

Instruction of Product Installation:

pu sandwich roof panel is to be connected onto the purlin with tapping screws and to be connected with the other board through lapping.
(1)Connected by secret nail, no screws on the exposed surface, so the building wall is beautiful and graceful.
(2)High flexural capacity, superior wall mechanical properties, reducing reliance on secondary steel structures.
(3)Good temp-keeping and heat insulation, reducing the cost of indoor air conditioning unit.
