Недорогие Макси ups для домашнего использования 10 кВА/8 кВт с
- Категория: Источники бесперебойного питания >>>
- Поставщик: Foshan,Xinchen,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 400.65 $* | 420.9 $* |
| Aug-18-2025 | 396.92 $* | 416.72 $* |
| Jul-18-2025 | 333.47 $* | 350.82 $* |
| Jun-18-2025 | 390.40 $* | 410.74 $* |
| May-18-2025 | 339.74 $* | 356.50 $* |
| Apr-18-2025 | 383.80 $* | 402.41 $* |
| Mar-18-2025 | 380.89 $* | 399.75 $* |
| Feb-18-2025 | 376.30 $* | 395.20 $* |
| Jan-18-2025 | 373.82 $* | 392.2 $* |
Характеристики
Product Description
Specification
Model | 10K plus | 10KS plus | ||
Rating | 10KVA/9KW | |||
Input | Input system | Single phase & earth ground | ||
Voltage range | (120±5)VAC~ (274±5)VAC | |||
Power factor | ≥0.99 | |||
Voltage range of bypass | (60±5)VAC~ (300±5)VAC (default: 80VAC~264VAC Could be adjusted by software) | |||
Output | Output system | Single phase & earth ground | ||
Rated voltage | 220VAC | |||
Power factor | 0.9 | |||
Voltage precision | ±1% | |||
Output frequency | Normal mode | 1.The output frequency synchronizes with the input frequency when the input frequency is in the range of 46 Hz~ 54 Hz. 2.The output frequency is 50Hz when the input frequency is not in the range of 46 Hz~ 54 Hz. 3.Can be set as 60Hz.
| ||
Battery mode | ||||
Inverter overload capacity (Utility power, 25℃) | 105% ±5% < Load ≤ 125% ± 5% 60s transfer to bypass 125% ±5% < Load < 135% ± 5% 30s transfer to bypass Load > 135% ± 5%, 100ms transfer to bypass | |||
Transfer time | 0ms (Normal mode←→ Battery mode) | |||
<4ms (Normal mode←→Bypass mode) | ||||
Crest factor | 3:1 | |||
Battery | Batteries voltage | 192VDC | ||
Battery quantity | 16 | None | ||
Battery Type | Sealed maintenance-free lead –acid battery of battery voltage 12V/7AH | |||
Backup Time (25℃) | Full load ≥ 5min (Standard) | |||
Charge current | 1A | 5.5A | ||
Dimensions (L*W*H)mm | 533x260x560 | 533x260x501 | ||
Weight (kg) | 62 | 21 | ||
Note1: Output voltage can be set: 200V/208V/220V/230V/240V.
2.Operating environment
Temperature | Humidity | Altitude | Storage temperature |
0℃-40℃ | <95% | <1000m | 0℃-40℃ |
Note: If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be decreased in use, please refer to the following:
Altitude(M) | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 |
Load | 100% | 95% | 91% | 86% | 82% | 78% | 74% | 70% | 67% |
