Item: Best price Epistar chips 588-595nm 5mm piranha led Yellow
Warranty: 3 years
Lifespan > 80 000hours
Super low decay version
Packing: 1000pcs/ESD bag
Certificate: CE/RoHS /Reach
3mm super flux led | |||||
Single chips | |||||
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-113TW-1 | 2500-3000mcd | 90deg | From 2500 to 20000K | 20-30mA | 3.0-3.4V |
FD-113TW-2 | 3000-5000mcd | 90deg | 20-30mA | 3.0-3.4V | |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-113TR-1 | 800-1200mcd | 90deg | 620-625nm | 20-30mA | 1.9-2.4V |
FD-113TR-2 | 1500-2500mcd | 90deg | 620-625nm | 20-30mA | 1.9-2.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-113TY-1 | 700-900mcd | 90deg | 588-595nm | 20-30mA | 1.9-2.4V |
FD-113TY-2 | 1000-1500mcd | 90deg | 588-595nm | 20-30mA | 1.9-2.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-113TG-1 | 3500-4500mcd | 90deg | 520-525nm | 20-30mA | 3.0-3.4V |
FD-113TG-2 | 5000-7000mcd | 90deg | 520-525nm | 20-30mA | 3.0-3.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-113TB-1 | 500-700mcd | 90deg | 460-470nm | 20-30mA | 3.0-3.4V |
FD-113TB-2 | 1000-1200mcd | 90deg | 460-470nm | 20-30mA | 3.0-3.4V |
5mm super flux led | |||||
Single chips | |||||
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-115TW-1 | 3000-4000mcd | 90deg | From 2500 to 20000K | 20-30mA | 3.0-3.4V |
FD-115TW-2 | 4000-6000mcd | 90deg | 20-30mA | 3.0-3.4V | |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-115TR-1 | 1000-1500mcd | 90deg | 620-625nm | 20-30mA | 1.9-2.4V |
FD-115TR-2 | 2000-3000mcd | 90deg | 620-625nm | 20-30mA | 1.9-2.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-115TY-1 | 1000-1200mcd | 90deg | 588-595nm | 20-30mA | 1.9-2.4V |
FD-115TY-2 | 1500-2000mcd | 90deg | 588-595nm | 20-30mA | 1.9-2.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-115TG-1 | 4000-5000mcd | 90deg | 520-525nm | 20-30mA | 3.0-3.4V |
FD-115TG-2 | 6000-8000mcd | 90deg | 520-525nm | 20-30mA | 3.0-3.4V |
Part No. | Intensity | Angle (Degree) | CCT available/ Wavelength | Current(mA) | Voltage( V) |
FD-115TB-1 | 700-1000mcd | 90deg | 460-470nm | 20-30mA | 3.0-3.4V |
FD-115TB-2 | 1200-1500mcd | 90deg | 460-470nm | 20-30mA | 3.0-3.4V |
5mm super flux with multi-chips | |||||
Double chips | |||||
Part No. | Color | Angle (Degree) | CCT & Wavelength | Current(mA) | Voltage( V) |
FD-115TW2 | White | 90deg | From 2500 to 20000K | 40mA | 3.0-3.4V |
FD-115TR2 | Red | 90deg | 620-625nm | 40mA | 1.9-2.4V |
FD-115TY2 | Yellow | 90deg | 588-595nm | 40mA | 1.9-2.4V |
FD-115TG2 | Green | 90deg | 520-525nm | 40mA | 3.0-3.4V |
FD-115TB2 | Blue | 90deg | 460-470nm | 40mA | 3.0-3.4V |
4chips | |||||
Part No. | Color | Angle (Degree) | CCT & Wavelength | Current(mA) | Voltage( V) |
FD-115TW4 | White | 90deg | From 2500 to 20000K | 80mA | 3.0-3.4V |
FD-115TR4 | Red | 90deg | 620-625nm | 80mA | 1.9-2.4V |
FD-115TY4 | Yellow | 90deg | 588-595nm | 80mA | 1.9-2.4V |
FD-115TG4 | Green | 90deg | 520-525nm | 80mA | 3.0-3.4V |
FD-115TB4 | Blue | 90deg | 460-470nm | 80mA | 3.0-3.4V |
0.5watt | |||||
Part No. | Color | Angle (Degree) | CCT & Wavelength | Current(mA) | Voltage( V) |
FD-115TW5 | White | 90deg | From 2500 to 20000K | 150mA | 3.0-3.4V |
FD-115TR5 | Red | 90deg | 620-625nm | 150mA | 1.9-2.4V |
FD-115TY5 | Yellow | 90deg | 588-595nm | 150mA | 1.9-2.4V |
FD-115TG5 | Green | 90deg | 520-525nm | 150mA | 3.0-3.4V |
FD-115TB5 | Blue | 90deg | 460-470nm | 150mA | 3.0-3.4V |
Best price Epistar chips 588-595nm 5mm piranha led Yellow
1. FEDY is a professional manufacturer of high quality led diode since 2000
2. Class A quality with 3 years warrany for all items.
3. Orignal Epistar/Bridgelux chips with 100% Class A grade.
4. All leds 100% QA passed before shipped.
5. Fully automatic production machine and quality checking machines insure great quality of goods , and fast delivery .
FAQ
1) How can I place order?
A: You can contact us by email about your order details.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) , Paypal, or Western Union are the most usual ways we are using.
3) What's the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pre-paid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-10days if we don't have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
Best price Epistar chips 588-595nm 5mm piranha led Yellow
All the raw materials we used are CE ROHS Applied .
Best price Epistar chips 588-595nm 5mm piranha led Yellow
Contact us freely !
Best price Epistar chips 588-595nm 5mm piranha led Yellow
Packing details :
SMD LED : Reels
DIP LED : ESD bag , Taping . Tubes
High power led : ESD box . Taping , Tubes
Shipping :
