high grade 70hp 80hp 90hp 4*4 farm wheel tractor



1. JIULIN TB chassis Tiger series tractor farm tractor is designed for multiple heavy works in small or medium farm.it can be matched with various implements to deal with different agricultural working conditions.

2.Equipped with Chinese famous four-cylinder diesel engine,from 70-90hp, it has the advantage of low fuel consumption: low maintenance cost and large torque output

3.Using central console, mature structure and enhanced axles, the tractor is easy to control and maintain, optional side console for ariving and riding comfort.

4.Standard with 12F+12R shuttle shift gearbox to meet the requirements on more rational speeds.

5.Standard with dual-action clutches from 10 to 11 inches for different needs and operation.

6.Optional Herringbone tires, paddy tires or other type of tires to meet your needs of working conditions.ROPS,canopy and cabin is optional to meet different working conditions.

7.Hydraultc power steering makes it easy to control and reduce the labor strength of operaton.

8.Rear working light

9. tractor tool box,English manual,ect

10. color: as requires

11.Maintenance-free battery, Rear-mounted three point suspension

12.Streamline engine cover

13. other Specification

Model			TB704
Type			4×4
Overall Dimension (mm)	L×W×H		3900×1795×2300
	Tread	Front Wheel	1300
		Rear Wheel	1200,1300( usual),1400
	Wheel Base		2072
	Min. Ground Base		390 (the bottom of steering horizontal pulling rod)
Min. Usage Mass (kg)			2700
Engine	Model		Quanchai4108
	Type		Vertical, water cooled and 4-stroke
	Rated Power(kw)		51.4
	Rated Rev.(r/min)		2400
	Fuel		Diesel Oil
Tire	Front & Rear Wheel		8.3-24/14.9-30
	Optional Front & Rear Wheel		9.5-24/16.9-30
Clutch			dry-friction, dual stage
Steering			Hydraulic type
Transmission Box			12F+12R Shuttle Shift
Suspension Type			Post Positioned Three-point Suspension Catalogue II
PTO	Type and Rev.(r/min)		Post-position, half-independent or independent, 540/760 or 540/1000
	Spline Size		I35 Rectangle Spline with 6 teeth
Structure and specification are subject to change without notice.

options: all these types can optional for ROPS ,Sunshade,swing drawbar, front/rear ballast,cabin

CHINA JIULIN Tiger series line tractor  We are available to provide customers with a full range of products, including steel ,tractors, implements, harvesters. forest machines  and other systerm , for farm systerm,we can supply high reliability and good performance tractors and harvesters to the farmers from all over the world.



Packaging & Shipping

 Two methods of container packing:

Our Services

After-sales service polices:

1. JIULIN tractor is offered 12 months of warranty period of the tractor, which shall start from the shipment date.


2. JIULIN will offer free service parts in warranty period, and there is no charge for related work hours and indirect expenses.


3. Service training

There are over 70 dealers and service channels covering all the market area. We take "satisfy the customers" as our target, provide "3 Full" (Full course, Full time, Full hearted) service.
