Гидравлический фотогальванический заземляющий сваечный привод анкерный
- Категория: Сваебойная установка >>>
- Поставщик: Xuzhou,Hengxing,Jinqiao,Machinery,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.91 $* | 0.44 $* |
| Aug-16-2025 | 0.8 $* | 0.83 $* |
| Jul-16-2025 | 0.13 $* | 0.33 $* |
| Jun-16-2025 | 0.55 $* | 0.73 $* |
| May-16-2025 | 0.16 $* | 0.28 $* |
| Apr-16-2025 | 0.95 $* | 0.13 $* |
| Mar-16-2025 | 0.46 $* | 0.18 $* |
| Feb-16-2025 | 0.19 $* | 0.80 $* |
| Jan-16-2025 | 0.63 $* | 0.69 $* |
Характеристики
Hydraulic post driver for highway construction and ramming pile
Hot Sale Guardrail Hammer Ramming Pile Driver
2018 HXD PILE DRIVER
| HXR TECHNICAL PARAMETERS | |||
| NO | Item | Value | unit |
| 1 | Dimension | 3250*2300*5000(working) | mm |
| 5000*2300*2300(folded) | |||
| 2 | Net weight | 4500 | kg |
| 3 | Diesel engine power | 53 | kw |
| 4 | Working motor torque(max) | 5700 | Nm |
| 5 | Rotary motor torque(ground screw piling) | 4000 | NM |
| 6 | Rotary motor torque(auger drilling) | 4000 | NM |
| 7 | Post length(max) | 3500 | mm |
| 8 | Ground screw length(max) | 3500 | mm |
| 9 | Drilling depth | 3500 | mm |
| 10 | Ground screw pilling depth | 3500 | mm |
| 11 | Drilling diameter(auger drilling) | 0-300 | mm |
| 12 | Drilling auger(left/right) | 10/30 | ° |
| 13 | Drilling auger(forwards/backwards) | 70/30 | ° |
| 14 | Hydraulic system pressure | 16 | Mpa |
| 15 | Total hysdraulic systerm flow | 70 | l/min |
| 16 | Rotary motor flow | 70 | l/min |
| 17 | Ralking speed | 0-1600 | m/h |
| 18 | Chassis spec | 2002*1800*350 | mm |
| 19 | Width of steel chassis track | 350 | mm |
| 20 | Track height above the ground | 230 | mm |
| 21 | Grade ability | 15/30 | ° |
| 22 | Track turn rate | 1:21.4 | |
| 23 | Tracking working pressure difference | 13 | mpa |
Adantage of HXR5 pile driver:
1 Intensive lifting guide rail,with inlaidnylon material,slide smooth,adjustable gap,extending using life.
2 Folded hydralic hammer,convenient for transportation.
3 Alloy nlaid strop in the slid guide rail make using life longer.
4 Disc brake and drum brake ,hight saftey factor.
Application field:
1 Pile driving or driliing holes for highway guardrail intallation
2 Screw pile intallation for Pv power station .
3 Plie driving for other sites (such as farm,pasture,orchard etc.)
Contact me if you are interested our products:
Hot Sale Guardra
