SPT5535LV-360 35 кг 360 градусов сервопривод с непрерывным вращением Rc автомобильный сервомотор высоким крутящим моментом и низким
- Категория: RC Parts & Accs >>>
- Поставщик: Hangzhou,Reacher,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 14.46 $* | 14.74 $* |
| Jul-19-2025 | 11.43 $* | 11.42 $* |
| Jun-19-2025 | 14.40 $* | 14.65 $* |
| May-19-2025 | 14.17 $* | 14.58 $* |
| Apr-19-2025 | 11.10 $* | 11.13 $* |
| Mar-19-2025 | 13.5 $* | 13.67 $* |
| Feb-19-2025 | 13.21 $* | 13.4 $* |
| Jan-19-2025 | 13.6 $* | 13.85 $* |
Характеристики
SPT5535LV-360 35KG 360 Degree Continuous Rotation Servo Rc Car Steering Servo Motor High Torque Low Rpm
Dead band:4μs
Neutral Position:1500μs/50hz
Motor: Core motor
500-2500μs:360 Continuous Rotation
Voltage range:4.8V-6.0V
Operating Speed(4.8V):49rpm
Operating Speed(6.0V):61rpm
Stall Torque(4.8V):29 kg.cm
Stall Torque(6.0V):35 kg.cm
Dimensions:40.5X20X40.5mm
Weight: 57g
Connector Wire Length: JR 260 mm
Bearing: 2BB
OEM/ODM Order question
| * For the SERVOS please let us know your requirements: 1. Which Area you used for? RC Servo or Industry Servo? 2. What's your expected torque? 3. What's your expected speed? 4. Do you have serice life requirement? 5. Your working voltage please. 6. Do you have location dimension limited? If so, please let us know the maximum size. 7. Do you need it waterproof? 8. How many qtys you need? 9. Other requirements if you need, for example, wire length, connector types and so on. * For the MOTORS please let us know your requirements: 1. Please choose inrunner motor or outrunner motor you need. 2. Do you have motor diameter and length limited? 3. What working voltage you will use for this motor? 4. What's your expected rated power? 5. What's your expected RPM? 6. You battery pack can bear how high peak current? 7. You estimated yearly sales qty? 8. Do you need the speed controller as well or if you have yours,let us know the spec. 9. Other requirements if you need, for example, wire length, connector types etc. Contact us directly via Trade Manager or send us email, we will reply ASAP in 24 hours. Below our custom made motors for other clients for your information. |
Certificate:
