2 4 GHz WiFi 14dBi Наружная Направленная панельная
- Категория: Коммуникационная антенна >>>
- Поставщик: Shenzhen,Minsta,Electronics,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 9.52 $* | 9.21 $* |
| Jul-20-2025 | 7.33 $* | 7.40 $* |
| Jun-20-2025 | 9.14 $* | 9.2 $* |
| May-20-2025 | 9.4 $* | 9.14 $* |
| Apr-20-2025 | 7.19 $* | 7.48 $* |
| Mar-20-2025 | 9.68 $* | 9.24 $* |
| Feb-20-2025 | 8.0 $* | 8.49 $* |
| Jan-20-2025 | 8.84 $* | 8.6 $* |
Характеристики
Product Description
2.4GHz Outdoor Panel Antenna -14dBi
Feature:
- Directional
- Good impact resistance,waterproofing and anticorrosion ability
- Full day working
- Wide bandwidth
- Low VSWR
Application:
2.4GHz ISM band
Wireless LAN
IEEE802.11b,g,n.
Data Transmission
Wireless Film&Audio&Video system
Specifications
Electrical Specifications | |
Frequency range(MHz) | 2400-2483 |
Bandwidth(MHz) | 83 |
Gain(dBi) | 14 |
Half-power beam width(°) | H: 30 V: 30 |
VSWR | ≤1.5 |
Input Impedance(Ω) | 50 |
Polarization | Vertical |
Maximum input power(W) | 50 |
Lightning protection | DC Ground |
Input connector type | N Female/SMA |
Mechanical Specifications | |
Dimensions (mm) | 225*175*30 |
Antenna weight(kg) | 0.7 |
Operating temperature(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Radome material | ABS |
Radome color | white |
Mounting | pole-holding |
Mounting Pole Diameter(mm) | 35 - 50 |
