Model Features

1. US Copeland scroll compressor flexible , unique radial and axial flexible scroll to enhance the efficiency and

reliability of the compressor

2. EMERSON imported refrigeration parts , the use of limited length

3. The weld of brass pipe is non-exidization(nitrogen flushing)

4. High efficiency evaporator and condenser , can save more than 30% energy

5. Electrical part omron, FUJI, Schneider, LG, TE original authentic

6. Control: microcomputer touch control , LCD display

7. Remote switch function

8. RS-485 communication function for automated management ( optional )

9. Perfect safety protection , fault display, easy repair and maintenance without professionals

10. 10HP above uses two compressors can be used alone or in combination



Safety system

1. Circuit Breaker                                         8. Refrigerant Safety Valve

2. Pump Reverse protective                                9. Buzzer

3. Pump Overload Protective                               10. High-Pressure Gauge

4. Compressor Overload Protective                         11. Low-pressure Gauge

5. Heat-Exchange Fail Protective                           12. Water-Pressure Gauge

6. Refrigerant Shortage Protective                          13. Phase Failure Protecter

7. Freeze Protector



  Specifications



Model			AC-1A	AC-3A	AC-5A		AC-8A	AC-10A	AC-15A	AC-20A	AC-30A	AC-40A	AC-50A
Parameters
Control range			5℃-35℃
Refrigerating capacity		KW	2.85	7.95	13.4		20.8	26.8	41.6	55.5	81.25	111	125.7
		Kcal/H	2451	6837	11524		17888	23048	35776	47730	69875	95460	108102
Total input power		KW	1.47	3.05	5.38		8.25	10.76	15	20.2	29.4	40	44.4
Power supply			1P 220V 50Hz	AC 3P+PE 380V 50Hz (Or 200V/220V/415V 50Hz/60Hz)
Refrigerant	Name		R22 (Or R134a/R407c)
	Control mode		Capillary			Outside the balanced thermal expansion valve
Compressor	Type		Closed rotary	Copeland Compliant Scroll series regular
	power (KW)		0.95	2.68	4.63		6.75	4.63*2	6.75*2	9*2	13.6*2	9*4	10.1*4
Condenser	Type		Efficient aluminum finned copper jacket + low noise external rotor fan
	Air cooling capacity		1000	3000	5000		8000	10000	15000	20000	30000	40000	50000
	(m3/h)
Evaporator	Type		Tank coil			Shell and tube
	Chilled water  (L/min)		10	48	58		120	120	208	250	416	500	700
	Water tank (L)		25	45	85		120	180	280	280	420	550	650
	Chilled water pipe		1/2“	1”	1“		1-1/2”	1-1/2“	2”	2-1/2“	2-1/2”	3“	3”
Water pump	power (KW)		0.37	0.37	0.75		1.5	1.5	1.5	2.2	2.2	4	4
	H (m)		18	15	25		20.5	20.5	20	21	19	24	21
Size	L(mm)		600	950	1200		1300	1450	1800	2000	2000	2100	2350
	W(mm)		450	550	600		700	780	900	1150	1450	1600	1700
	H(mm)		850	1000	1100		1300	1450	1650	1600	1800	1900	1900
Weight	kg		80	140	180		310	400	600	720	1150	1250	1450
