FL & OEM 4CH видео/аудио вход WIFI GPS людей подсчет системы 4G в реальном времени 1080P HD автомобиль MDVR транспортное средство пассажирский


Поделиться:


Цена:480,00 $ - 495,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 571.42 $* 600.44 $*
Aug-18-2025 566.88 $* 594.48 $*
Jul-18-2025 475.57 $* 499.99 $*
Jun-18-2025 557.91 $* 585.95 $*
May-18-2025 485.66 $* 509.48 $*
Apr-18-2025 547.93 $* 574.78 $*
Mar-18-2025 542.70 $* 569.63 $*
Feb-18-2025 538.81 $* 565.23 $*
Jan-18-2025 533.42 $* 560.60 $*

Характеристики



Product Description


Front Panel



Back Panel







Product Features


1.
H.265 Compression, saves storage costs, smoothly live streaming, clear picture quality, multi-stream recording.
2.
Support Dual SD Card (Max 256GB/each) Storage, completely protect the data from damage.


3.
Watchdog abnormal restart function protection, Better machine and data protection.
4.
Flameout delay recording function, ACC Delay off,can set 24 hours.


5.
On board UPS 8~10 seconds delay power-off for data protection.
6.
Support remote management, voice intercom, fuel monitoring, cut engine remotely function.


7.
Designed with RS232/RS485 and RJ45 peripheral interface.
8.
Allow to integared with Fuel Sensor,Temperature & Humidity Sensor, RFID card-reader,Tire pressure monitor and so on.


9.
8V~36V wide voltage power supply, Overload/ undervoltage/ short circuit protection, low voltage automatic shutdown.
10.
Al-aluminum profile design, small size, fast heat dissiption, dustproof, shockproof.


Product Advantages


1.The original Haith chip
Further Video Recorder, each of which uses the original industrial-grade Heise chip, can ensure stable operation in the severe cold and heat environment.
2. Humanized USB Interface
Humanized design, easy to operate, user-friendly copy of information, insert mouse/U disk.


3. Support screen switching
Supporting reverse screenenlargement, four-way video switching, providing technical support.
4. Wide Voltage Design
Vehicle broadband power supply can work steadily in the range of DC8V-36V voltage.


Monitor screen
4CH AHD 720P SD Mobile DVR 128GB CCTV Video Camera System Vehicle MDVR


Vehicle Survilliance Solutions
Vehicle Survilliance Solutions


Product-Apply-To
Bus ,Coach ,School Bus, Truck ,Tanker, Harvester


DVR installed in bus
Wholesale 4CH 8CH H.265 720P AHD Dual SD Card Slot G-Sensor GPS 3G DVR Mobile DVR


DVR installed in logistics vehicle
DVR installed in police car


DVR installed in taxi
DVR installed in oil truck


Four-channel simultaneous recording, smooth picture quality
Support parallel preview and return visit of different channels under multi-screen splitting


Loop recording, automatic coverage
When it detects that the hard disk space is insufficient, the system intelligently deletes the early unlocked screens, without manual operation, you can cycle the recording


3G/4G remote real-time monitoring
Insert a 3G/4G phone card, download the client, you can support multi-device terminal viewing, real-time sharing, remote download,real-time video you want to watch


GPS (Beidou) positioning
Carrying out vehicle positioning through GPS, knowing the location and driving trajectory of the vehicle, realizing the real-time scheduling of the vehicle and improving efficiency


Product Paramenters


Main processor
Hi3521D V100 chipset
High performance chipset
System
Language
Chinese, English, Russian (customerized)
Operation interface
OSD menu

Password security
User Password and Administrator Password
CUI
Image OSD
Can be connected to an external AV display and VGA display, Remocontrol operation setting system parameters
Interface

Audio
and
video
Video input
4/8-channel video input, 4pin interface, 1.0Vp-p, 750Ω
Video output
1 channel AV composite audio and video output, 4pin interface, 1.0Vp-p, 750, 1 channelVGA output
Audio input/output
4/8 input, 1 output,4pin interface
Compression Format
Encoding format: G726 40KBPS, Sampling rate: 8000 sample bit width, 16bit Sampling points: 320;
Preview
1/2/4/6/8/9 screen split preview, support manual/event trigger full screen display function
Resolution
Support 1080P/960P/720P/D1/HD1/CIF, MAX:8 channels 1080p
Video Quality
1-8 levels, 1 is the highest level, 8 is the lowest level.
Video Standard
PAL: 100 frames/s, CCIR625 line, 50 games NTSC: 120frames/s, CCIRS25 line,60Games;
1080P:1536Kbps~ 8Mbps, Multi-level image quality optional
720P:1000 Kbps ~ 6Mbps, Multi-level image quality optional Di: 800Kbps ~ 3Mbps, Multi-level image quality optional
HD1: 600Kbps ~ 2.5Mbps, Multi-level image quality optional
CIF: 256Kbps ~ 1.5Mbps, Multi-level image quality optional
Video mode
The default: auto recording after power on.
Ignition recording, alarm trigger recording and manual recording are supported.
Videostorage
File format
H.265
File system
Special file system or FAT32
SD CARD
Support 2SD card, Max 256G/each, cyclic recording
Upgrade method
Support USB flash disk updating 1 SD card upgrade
Video playback
Search video and video files by recording time, recording mode, etc.
Supports up to 4 channels of synchronized playback, pauses, fast forwards, rewinds,
supports 2, 4, 8, 16 times faster forward of backward
Alarm
Alarm input
4-channel alarm input with alarm linkage function
Alarm Output
2-Channel alarm output
G-Sensor
Support built-in G-SENSOR acceleration sensor, alarm linkage trigger
Port
RS232
1*RS232
RJ45
1*RJ45
USB
1*USB
Module
3G(Optional)
Built-in 3G module (WCDMA/EVDO/TD-SCDMA)
4G(Optional)
Built-in 4G module (TD-LTE/FDD-LTE)
WIFI(Optional)
Built-in WIFI module (2.4G)
GPS(Optional)
Support Dual Module GPS/BD
Software
CMSV6 Client
4G remote real-time monitoring GPS positioning, remot management, recording, playback,
intercom, monitoring, track playback alarm processing.
Mobile phone terminal
Remote real-time monitoring, GPS positioning. recording playback, intercom, monitoring,and alarm prompts are available anytime
and anywhere.
PC playback
Video playback track playback and analysis
Power
Power management
Wide voltagepower supply Overload 1 undervoltage I shor circuit protection, low voltage automatic shutdown, Support timer switch,
delay shutdown function.
Input voltage
DC:+8V ~ +36V
output voltage
+12V@1A, +5V@1A
Working environment
Temperature
-20'C to +70"C
Humidity
20% to 80%
Size
Machine
142mmx145mmx49mm


Cameras for mobile dvr(optional)
Cameras for mobile dvr(optional)


Company Profile




Further Technology (Dongguan) Co., Limited is a professional high-tech enterprise for R&D, manufacturing and marketing SD card Mobile DVR, hard drive DVR, 3G/4G/GPS/GPRS/WIFI Mobile DVR/NVR,GPS tracker and CCTV camera, which is the best manufacturer specialized in vehicle security products in China.In China and abroad, we have won a good reputation and had many success stories. In China, more than 2000 transport companies choose our products. Our products are made to meet safety standards such as CE, FCC and RoHS.
With more than 12 years of OEM/ODM experience, our manufacturing has successfully supported name brands worldwide with quality products with a strong R&D capability and our qualified products have been exported all over the world covering Asia, North &South America, Europe, Oceania, Middle East countries.
We are proud to provide the highest possible level of service to every customer and committed to provide superior quality products at lowest price possible. In addition to our commitment, we continue to keep an update on all our products, making sure it is up to today's technology and to maintain our product are always on top of the market.


Certifications




Packing & Delivery




Carton box


FAQ


1. who are we?
We are based in Guangdong, China, start from 2007,sell to Domestic Market(40.00%),Southeast Asia(10.00%),Eastern Europe(8.00%),North America(7.00%),Northern Europe(7.00%),Western Europe(5.00%),Southern Europe(4.00%),Central America(4.00%),Mid East(4.00%),South America(3.00%),Eastern Asia(3.00%),South Asia(2.00%),Africa(2.00%),Oceania(1.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Mobile DVR,Mobile NVR,People Counter,CCTV Camera,Car Black Box

4. why should you buy from us not from other suppliers?
Further Technology (Dongguan) Co., Limited is a professional high-tech enterprise for R&D, manufacturing and marketing SD card and HDD Mobile DVR/NVR,GPS tracker and CCTV camera,People counter. Our products are made to meet safety standards such as CE, FCC and RoHS.

5. what services can we provide?
Accepted Delivery Terms: EXW;
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Russian

6.Does your Company support OEM or ODM service?
Yes, our company has our own R&D department, and factory , can support OEM & ODM Service.

7. Does your MDVR System has CE FEE E-Mark?
Yes, our MDVR System has CE FEE E-Mark Certifications.

8.How about your quality control?
We have a very strict quality inspection step , 100% full Quality inspection

9. What is about your warranty?
For MDVRS, the warranty is 12 month, for Cameras,the warranty is 24 month. But actually we give Lifetime maintenance services, over the warranty period, only need to pay the cost of replacement parts , other maintenance services are free.
