PBS-29 игровой аксессуар круглой формы кнопочный
PBS-29 игровой аксессуар круглой формы кнопочный
PBS-29 игровой аксессуар круглой формы кнопочный
PBS-29 игровой аксессуар круглой формы кнопочный
PBS-29 игровой аксессуар круглой формы кнопочный
PBS-29 игровой аксессуар круглой формы кнопочный

PBS-29 игровой аксессуар круглой формы кнопочный


Поделиться:


Цена:0,29 $ - 0,35 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-20-2025 0.89 $* 0.85 $*
Aug-20-2025 0.72 $* 0.35 $*
Jul-20-2025 0.88 $* 0.99 $*
Jun-20-2025 0.94 $* 0.13 $*
May-20-2025 0.50 $* 0.31 $*
Apr-20-2025 0.35 $* 0.70 $*
Mar-20-2025 0.94 $* 0.9 $*
Feb-20-2025 0.62 $* 0.47 $*
Jan-20-2025 0.81 $* 0.83 $*

Характеристики





Name
Push Button Switch
Protection Level
IP40
Max.Current
16A
Max.Voltage
250VAC
Certificate
CE,Rohs,,CQC
Electrical Life
100,000Cycles
OEM&ODM
Yes


Model
PBS-29
Type
Game Machine Push Button Micro Switch LED Illuminated
Rating
16A 250V
Mounting Size
28mm
Light
Without Light
Terminal
2 Pin/3 Pin, Solder Terminal
Degree of Protection
IP40
Switch Color Avaliable
White/Black/Red/Green/Yellow/Blue
Operating Temperature
-25°C ~+85°C
Contact Resistance
50mΩ max.
Insulation Resistance
100MΩ min. 500V DC
Dielectric Strength
AC 1500V 1 minute
Electrical Life
10,000 cycles min




PBS-29

Specifications:
1. Rating: 16A 250VAC
2. Electrical Life: 10,000 Cycles
3.Contact Resistance: 50mΩ max
4. Insulation Resistance:DC500V 100MΩ min
5. Dielectric Strength:1500V AC 1min
6. Operating Temperature:-25°C~+85°C
7. Function: Momentary Push Button Switch
8. Operating Force: 5N Max

Push button switch is one of the most easy and quick to operate. The Switches, buttons are more attractive in appearance and the
material that are used illuminative its surface, labeled as graphic convenience, operating the switch lead to the user
satisfaction, can also be used in SMART CAP system where one can input device products, this is definitely the best choice for
designers









1.Q: Could I put my own logo on the products?
   A: Sure, your logo can be put on every product, either by laser, or by moulds.

2.Q: Could I put my own designs of label on the products?
   A: Of course, you can send us your design, we'll follow your design.

3.Q: Can I have some samples before formal order?
   A: Yes. we can send you some free samples for your test before your order.

4.Q: How long is the lead time?
   A: Normally we keep stock for most products, the lead time is 1-5 days as soon as the payment is released.
        For customized products, it takes longer.

5.Q: How about the after-sale service? What's the Warranty terms?
   A: We offer 12 months for every products we sold. If you meet any problems after sales, pis contact us freely,
        we'll help solving the problems within 24 hours.

6.Q: Are you manufacturer or just dealer?
   A: We're manufaturer, we do produce all products by ourself. Welcome to visit our plant at any time.

7.Q: What's the payment terms? Can I pay after you got the products?
   A: Normally we accept TT and western union. L/C is also accepted if the order quantity is large. For old customers,
        we'll guanartee monthly payment after good cooperationship.

8.Q: I couldn't find the products I want in your catalogue, can you develop it for me?
   A: Yes. we have a research & development dept.
