3-х тонный подъемный крюк для

Категория: Мусоровоз >>>
Поставщик: Hubei,Jiangnan,Special,Automobile,Co.,Ltd.

Цена:302 417,36 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-16-2025	384070.92 $*	391751.95 $*
Jul-16-2025	311490.96 $*	317720.98 $*
Jun-16-2025	378021.46 $*	385581.41 $*
May-16-2025	374997.10 $*	382497.21 $*
Apr-16-2025	299393.17 $*	305381.20 $*
Mar-16-2025	368949.94 $*	376328.34 $*
Feb-16-2025	365925.14 $*	373244.51 $*
Jan-16-2025	362900.50 $*	370158.44 $*

Характеристики

Product Description

Gvw of the vehicle (t)	4.05	Body width（mm）	1060
Capacity (Ton)	3	Installation height（mm）	145
H = Hook height (mm)	930	MIN. Free tunnel height(body) (mm)	80
L = G-length (mm)	2700	Centre of gravity (mm)	1440
LR = Container length (internal) (m)	3.0-3.5	S = Sliding distance（mm）	545
Tipping angle (º)	49°	Max. operating pressure (mpa)	250
Equipment weight (kg)	460	Recommended oil flow (l/min)	15-20

Detailed Images

Manufacturing Technique

The hook-arm garbage truck is a special vehicle used for garbage transfer and unloading operations in urban garbage compression stations.

It consists of a car chassis, a dump cylinder, a rear door cylinder, an attached frame, a garbage bin and a rear door swing lever.

The operation is completed by the hydraulic control system, and the control mode can be manual or electrical control.

It is mainly used for garbage removal in urban and rural garbage compression stations.
