Специальный регулятор температуры формы для литья под

Описание и отзывы

Трекер стоимости

Характеристики





Model Features

1. Highest temperature reaching 350℃

2. Microcomputer touch screen, easy operation

3. Germany SPECK magnetic drive pumps , temperature 350 ℃, never leak

4. Return oil back suction of oil pump

5. Automatic exhaust function as starting up the machine

6. Outlet and inlet temperature display

7. Multi-stage heating , power can be switched

8. Forced cooling

9. Remote switch function

10. By-pass pressure release loop for hot oil

11. Electrical part omron, FUJI, Schneider, LG, TE original authentic

12. S.S.R. control

13. Special piping system design , oil is not oxidized , long life

14. high temperature insulation materials , energy conservation and heat loss

15. stainless steel integrated pipelines for less pipe resistance and rust

16. Isolated electric control box , to extend the life of appliances

17. Perfect safety protection , fault display, easy repair and maintenance without professionals





  Specifications



Model	Unit	ATCO-3515S-YTC	ATCO-3540S-YTC	ATCDO-3507S-YTC	ATCDO-3515S-YTC	ATCDO-3540S-YTC	ATCDO-3555S-YTC
Control range	℃	60℃-350℃
Temp.control accuracy	℃	PID±0.1℃ or ±1℃
Power supply		AC 3P+PE 380V 50Hz  (6M )
Heat transfer medium		conduction oil
Cooling method		Indirect cooling
Heating capacity	KW	18	36	9+9	18+18	36+36	48+48
Pump power	HP	1.5	4	0.7+0.7	1.5+1.5	4+4	5.5+5.5
Max pump flow	L/min	60	100	30+30	60	100	200
Max pump pressure	kg/cm2	6	7.5	5+5	6+6	7.5+7.5	9+9
Cooling water supply	kg/cm2	1	1	1	1	1	1
Oil tank	Liter	40	60	40	50	80	80
Power supply	KW	19.5	39	19.5	39	78.5	104.5
Cooling water pipe	INCH	1/2	1/2	1/2	1/2	1/2	1/2
Circulation oil pipe	INCH	3/4	1-1/4	3/4×2	3/4×2	1×2	1-1/4×2
Size (L×W×H)	CM	80×32×80	115×45×110	134×65×135	134×65×135	134×65×135	134×65×135
Weight	kg	110	200	180	240	290	350
Applicable model of die casting machine	T	250T	350T-450T	250T	250T-630T	650T-1800T	2200T
