Промышленный modbus rtu цветной сенсорный дисплей hmi 10
- Категория: ПЛК >>>
- Поставщик: Shenzhen,Coolmay,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 156.21 $* | 159.94 $* |
| Jul-17-2025 | 127.83 $* | 130.31 $* |
| Jun-17-2025 | 154.53 $* | 157.18 $* |
| May-17-2025 | 153.26 $* | 156.80 $* |
| Apr-17-2025 | 122.88 $* | 124.41 $* |
| Mar-17-2025 | 150.78 $* | 153.63 $* |
| Feb-17-2025 | 149.79 $* | 152.96 $* |
| Jan-17-2025 | 148.25 $* | 151.13 $* |
Характеристики
Industry modbus rtu color touch display hmi 10 inch
| Model | MT6037H | MT6043H | MT6050H | MT6070H | MT6100HA | MT6150HA | |
| Specs | Dimension | 88*88*25mm | 134*102*30mm | 146*88*25mm | 212*148*40mm | 275*194*36mm | 365*290*36mm |
| Cutout size | 72*72mm | 119*93mm | 135*72mm | 194*138mm | 261*180mm | 350*280mm | |
| Display size | 73*56mm | 97*56mm | 108*65mm | 154*87mm | 222*125mm | 304*228mm | |
| Weight(kg) | About 0.3 kg | About 0.33 kg | About 0.33 kg | About 0.54 kg | About 0.7 kg | About 3.414 kg | |
| Display | Display | 3.5” TFT | 4.3” TFT | 5” TFT | 7” TFT | 10.1” TFT | 15.0” TFT |
| Resolution(pixels) | 320*240 | 480*272 | 800*480 | 800*480 | 1024*600 | 1024*768 | |
| Brightness | 300cd/m² | 450cd/m² | |||||
| Contrast ratio | 400:01:00 | ||||||
| Backlight | LED | ||||||
| Backlight time | 60,000 h | ||||||
| Display color | 65536 true colors | ||||||
| Touch type | 4-wire resistive panel | ||||||
| Storage | ROM | 128MB | |||||
| RAM | 64MB | 128MB | |||||
| CPU | ARM9 core 400MHz | CORTEX A8 720MHz-1GHz | |||||
| Operating system | WINCE 5.0 | WINCE 7.0 | |||||
| Interface | USB port | USB 2.0×1 (USB port and can be connected to external USB flash drive, mouse, etc.) | |||||
| Download port | Yes (Mini type B male port cable for program download | Yes (Type B male port cable for program download) | |||||
| Ethernet port | Optional | ||||||
| COM port | 1 RS232 and 1 RS485 | ||||||
| Protocol | Support MODBUS, free port and common PLC communication Protocol | ||||||
| Calendar | Yes | ||||||
| Input Voltage | Default as DC24±10%V, and DC12V/DC5V can be optional | ||||||
| Consumption | 100mA*24V | 150mA*24V | 150mA*24V | 200mA*24V | 280mA*24V | 500mA*24V | |
| Protection Class | IP65 (front panel) | ||||||
| Temperature | Ambient environment: 0~50℃ | Storage environment: -20~70℃ | ||||||
| Humidity | 20%~90% RH | ||||||
| Certification | CE | ||||||
| Software | CoolMay HMI programming software | ||||||
| Detailed info. refer to CoolMay HMI user manual, CoolMay HMI programming manual | |||||||
Packaging & Shipping
- Packaging
The products will be under testing for 1-3 days and packed with carton box .
- Shipping
By courier, door to door
For samples, the package will be delivered by DHL/UPS/FedEx/EMS express. Usually it will take 3-7 days to your location.
Post service
If you are not hurry but need economical delivery, we can go with packet channel. The delivery time depends on your location.
Air shipping or by sea
If bulk order, the packages will be delivered by air shipping or by ship.
Company Information
All of our products are passed CE Certificate with low voltage and IEC Test.
Our Services
Coolmay develops and manufactures HMI, PLC, HMI+PLC all-in-one, modules with Coolmay own brand. We offer services anytime when you need help.
Your products will be strickly tested before shipping.
Maintenance and service
- Your products will be 18-month warranty excluding artificial damage.
- You would receive unlimited support via video, phone or email.
- OEM/ODM is supported, MOQ is 200 sets. More modules or functions can be customized as per your requirements.
