UL2587 pvc insulated copper conductor yellow colour sheathed cable

All our wires and cables are made of 99.99% pure oxygen free copper and high quality PVC which comply with the European Union RoHS environmental protection instruction.

SPECIFICATION:   UL2587 computer cable 28AWG  7/0.127mm  6 cores

RATED TEMPERATURE:  90  Deg Centigrade

RATED VOLTAGE: 600V

REFERENCE STANDARD: UL758

Pass FLAME TEST: UL VW-1,  FT1 flame test

Insulation material  : PVC

Sheath Material : PVC

Braid material :  copper

CONDUCTOR:stranded tinned copper

Conductor			Finished products
No.of Cores	AWG	Construction(No./mm)	Insulation Thickness	Jacket Thickness	Braid M/n/d	O.D.	MAX.COND. Resistance
2	26	7/0.16	0.76	0.76	0.20	6.10	45.75
	24	11/0.16				6.30	28.73
	22	17/0.16				6.65	18.12
	20	26/0.16				7.00	11.20
3	26	7/0.16	0.76	0.76	0.20	6.30	45.75
	24	11/0.16				6.60	28.73
	22	17/0.16				6.90	18.12
	20	26/0.16				7.30	11.20
4	28	7/0.127	0.76	0.76	0.20	6.50	72.89
	26	7/0.16				6.75	45.75
5	28	7/0.127				7.05	72.89
	26	7/0.16				7.30	45.75
6	28	7/0.127				7.70	72.89
	26	7/0.16				8.00	45.75
7	28	7/0.127				7.70	72.89
	26	7/0.16				8.00	45.75





     Q: Are you manufacturer or trading company?

     A: We are the factory who specialize in the production of ul electrical wire,automotive wire

          building wire , motor lead wire and solar cable since 2009.



     Q: How can I go to your factory?

     A: We are located in Lingkou Industrial Park , Danyang City , Jiangsu Province , China.

          There’re tow kind transportation methods.

          1) Flight to Shanghai , and aboard one-hour Harmony train from Shanghai Station to

          Danyang  Station.

          2)Flight to Changzhou , and aboard 20-minute Harmony train from Changzhou Station to

          Danyang Station.



     Q: Can you show us your products test report?

     A: Of course . I can e-mail the copy one to you.

         Our products have passed RoHS & REACH test.



     Q: Can I have the sample?

     A:  Yes . The free samples are available . You just need to afford the freight cost.



     Q: How long can I expect to get the samples?

     A:  If there’ stock , it can be delivered within 1 day . If not , it will be 3-5 days.



     Q: OEM can be accepted?

     A:  Yes , it can be accepted.



     Q: Some special wire can be producted?

     A:  Yes , we can do the customer wire according to your drawings or specifications.



     Q: What’s your delivery time?

     A:  It depends on your quantity
