2kw HYS-6PV-66-LSD с двумя осями системы Улавливателя солнечной энергии кронштейн для установки солнечных батарей Kit 2 оси GPS система питания от pв трекер защита высокой
- Категория: Улавливателя солнечной энергии >>>
- Поставщик: Shandong,Huayue,New,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1916.66 $* | 2012.76 $* |
| Aug-15-2025 | 1900.11 $* | 1995.12 $* |
| Jul-15-2025 | 1594.22 $* | 1674.72 $* |
| Jun-15-2025 | 1868.95 $* | 1961.59 $* |
| May-15-2025 | 1626.37 $* | 1707.18 $* |
| Apr-15-2025 | 1835.5 $* | 1927.80 $* |
| Mar-15-2025 | 1819.67 $* | 1910.33 $* |
| Feb-15-2025 | 1803.53 $* | 1893.59 $* |
| Jan-15-2025 | 1787.19 $* | 1876.76 $* |
Характеристики
Power generation comparison
Product features
Optional accessories
Product Paramenters
HYS-6PV-66-LSD Dual Axis Solar Tracker Structural Parameters | ||||||
Solar panel type | 1791*1052mm | Installed capacity | 2kw | |||
System weight | ≈400kg/sets | Number of solar panels | 6P | |||
Arrangement of solar panels | Horizontal arrangement | Ground clearance | 400mm | |||
Area of grid structure (m²) | ≈11㎡ | Bracket material | Hot dip galvanized steel | |||
Protection of wind speed | 17 m/s | Snow load | 0.5～1.6KN/㎡ | |||
Main material | Q235B / Q355B | Galvanizing thickness | ＞85m | |||
Fastener material | 304 stainless steel | Mechanical design life (y) | ＞25 | |||
Design code | ASCE7 EN1991 AS1170 GB50009-2012 | |||||
Foundation form | Concrete (customizable all steel foundation) | |||||
Extreme wind speed | 37 ~ 50M / S (ASCE7-10,other wind speeds can be customized) | |||||
Quality assurance period | The whole machine is guaranteed for 3 years (except for man-made damage and force majeure) | |||||
Working temperature (℃) | General default configuration -30℃ ~ +70℃ special customized configuration -50℃ ~ +85℃ | |||||
Dual Axis Controller Parameters | ||||||
Control algorithm | Astronomical algorithm + position sensor closed loop control | |||||
Controller type | MCU | Control core | MCU（32bit) | |||
Communication type | RS485 | Gale protection | have | |||
Night return mode | have | Backtracking algorithm | have | |||
Anemometer | have | Protection level | IP66 | |||
GPS | have | Heavy rain cleaning mode | Optional | |||
Drive protection | have | Snow removal mode | Optional | |||
System voltage | DC24 | Driving device | Slewing drive + Linear drive | |||
Driving power (W) | 150W | Tracking accuracy (°) | ≤1° | |||
Power supply mode | Self powered / external power supply | Azimuth tracking range (°) | -120 ° ~ + 120 ° / - 135 ° ~ + 135 ° (customizable) | |||
Daily power consumption (KWH) | ≤0.2kWh | Altitude angle tracking range (°) | 0~60° | |||
System power supply | L+N(two-phase input) 100V~240V AC(wide voltage input) | |||||
Network communication mode | RS485 | |||||
Network communication type | Bluetooth (customizable WiFi, 4G) | |||||
Rotating position protection mode | Sensor protection + software protection | |||||
