Гидравлический шланговый обжимной станок YONG FENG Y120
US $1950-$4100
Высококачественная немецкая оригинальная ОБЖИМНАЯ машина гидравлическая для прессования шлангов
- Категория: Rubber Product Making Machinery >>>
- Поставщик: Dalian,Barnett,Flex,Hydraulics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.1 $* | 0.71 $* |
| Aug-18-2025 | 0.17 $* | 0.40 $* |
| Jul-18-2025 | 0.41 $* | 0.48 $* |
| Jun-18-2025 | 0.47 $* | 0.47 $* |
| May-18-2025 | 0.48 $* | 0.86 $* |
| Apr-18-2025 | 0.64 $* | 0.99 $* |
| Mar-18-2025 | 0.94 $* | 0.15 $* |
| Feb-18-2025 | 0.29 $* | 0.42 $* |
| Jan-18-2025 | 0.22 $* | 0.42 $* |
Характеристики
CRIMPING MACHINES
BNT68
PROFESSIONAL WORKSHOP
BENCHTOP
BENCHTOP
KEY ADVANTAGES
• Ergonomic micrometer
•Radial die movement
•High crimping force
•Electronic control and semiautomatic opening
•Cylinder protection
•Easy front access for elbow fittings
•Energy savings
MAIN APPLICATIONS
Dedicated to hydraulic maintenance specialists working on medium sized machines and equipment. Also suitable for assemblers involved in medium sized hoses and quantities.
TECHNICAL SPECIFICATIONS
Motor:4KW
Noise Level:71dB
Crimp Range:10-87mmCrimp force:5000KN
Opening with dies:+30mm
Complete Opening:114mm
Master Die Length:70mm
Standard Dies:15,19,23,26,31,36,
41,47,55,60mm
Dimensions:730mm*480mm*740mm
Net Weight:245kg
Packaging:800*530*870mm
Gross Weight:260kg
Voltages:220/240 V, 3Ph, 50 Hz
380/415 V, 3Ph, 50 Hz
208/240 V, 3Ph, 60 Hz
380/415 V, 3Ph, 60 Hz
Capacity:2wb:2'' max.
4ws: 2” max.
6ws: 1” max.
Technical Features:
The BNT68crimping machine is a cost-effective alternative for single-piece production.
BNT68-models (precision, durability, force and ease of use), the 50model is totally unmatched in it's own class.
AVAILABLE DIE SETS
Product Code | Description | N° | Crimp Range(mm) | Die Length (mm) |
1 | Die set n. 15 - length 60mm | 15 | 15-19 | 60 |
2 | Die set n. 19 - length 60 mm | 19 | 19-23 | 60 |
3 | Die set n. 23 - length 60 mm | 23 | 23-26 | 60 |
4 | Die set n. 26 - length 60 mm | 26 | 26-31 | 60 |
5 | Die set n. 31 - length 70 mm | 31 | 31-36 | 70 |
6 | Die set n. 36 - length 70 mm | 36 | 36-41 | 70 |
7 | Die set n. 41 - length 75 mm | 41 | 41-47 | 70 |
8 | Die set n. 47 - length 80 mm | 47 | 47-55 | 80 |
9 | Die set n. 55 - length 80 mm | 55 | 55-60 | 80 |
10 | Die set n. 60 - length 80 mm | 60 | 60-69 | 80 |
Detailed Images
OUR RANGE OF BNT68 POWER MACHINES HAVE VARIOUS
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
Capacity: 2″ 4wb (may vary according to assembly material)
Crimp range: 10 – 87 mm
Crimp force: 500t
Crimp range: 10 – 87 mm
Crimp force: 500t
OUR RANGE OF BNT68 POWER MACHINES HAVE VARIOUS
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
Capacity: 2″ 4wb (may vary according to assembly material)
Crimp range: 10 – 87 mm
Crimp force: 500t
Crimp range: 10 – 87 mm
Crimp force: 500t
OUR RANGE OF BNT68 POWER MACHINES HAVE VARIOUS
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
OPTIONS OF CONTROL AND A WIDE RANGE OPTIONAL
EXTRAS TO SUIT WHAT YOU NEED.
Capacity: 2″ 4wb (may vary according to assembly material)
Crimp range: 10 – 87 mm
Crimp force: 500t
Crimp range: 10 – 87 mm
Crimp force: 500t
