Термоусадочная трубка DEEM в виде рыбьей чешуи противоскользящая термоусадочная для

Описание и отзывы

Трекер стоимости

Характеристики





Technical Data

Property	Test Method	Typical Data
Tensile Strength (Mpa)	ASTM D412	10.4 Mpa
Longitudinal Elongation(%)	ASTM D412	≤8
Elongation(%)	ISO 1210	200%

Dimensions

Size	As Supplied (mm)		After Recovery (mm)		Standard length m/pcs
DM-SP mm. (D)	Inside Diameter Min. (D)	Wall Thickness Nominal. (T)	Inside Diameter Max. (d)	Wall Thickness nominal. (t)
15	≥15	0.45±0.15	8	0.85±0.15	0.8/1.0/1.6
20	≥20	0.50±0.15	11	0.90±0.15	0.8/1.0/1.6
22	≥22	0.50±0.15	12.5	0.90±0.15	0.8/1.0/1.6
25	≥25	0.50±0.15	14.5	1.00±0.15	0.8/1.0/1.6
28	≥28	0.50±0.15	15.5	1.00±0.15	0.8/1.0/1.6
30	≥30	0.60±0.15	17.5	1.20±0.15	0.8/1.0/1.6
35	≥35	0.60±0.15	20	1.20±0.15	0.8/1.0/1.6
40	≥40	0.60±0.15	23	1.20±0.15	0.8/1.0/1.6
45	≥45	0.65±0.15	25	1.25±0.15	0.8/1.0/1.6
50	≥50	0.65±0.15	28	1.25±0.15	0.8/1.0/1.6



                                                Click here to send an enquiry!



DEEM Electronic&Electric Material Co Ltd is a joint venture manufacturer between Chinese sourcing company with a professional heat shrink backgroud specialist in Europe more than 20 years.We are specialized in research,develop,manufacturer and sales of radiation cross linked heat shrinkable material in worldwide.Such as thin wall,dual wall,medium wall,heavy wall and other specialty products like PTFE,PVDF,silicon rubber,crimp seal connectors,Fiber optic protectors,Braiding Sleeve and other kits in plastic box or small mini box etc related products.Meanwhile OEM and ODM service are available

DEEM is also able to provide any kind of added value jobs.Such as what we already did for the customer packing,cutting,loading,labeling,any kinds of kitting etc.Meanwhile we are also having the capacity to do the trading work as customer request in related fields.

Delivery.Efficiency.Economic.Material.Reliable service and products are servicing the customers more than 20 countries in worldwide.Welcome to join it.

FAQ

How and how long can I get a sample to check your quality? Can I expect to get the sample?
After product and price confirmation, you can require for samples to check our quality. the samples are free and will be ready for delivery in 3-5 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.

Can you do the design for us?
Yes. we are a perfessional manufacturer who can provide you OEM service.

What about the lead time for mass production?
It depends on the order quantity and the season you place the order.  Generally speaking, We suggest that you start inquiry two months before the date you would like to get the products at your country.


What kind of payment do you accept ?
We accept T/T(Wire transfer), Please be sure that we can receive the same amount of the Invoice.





Why choose us?
1. We have more than 10 years of experience in this industry and export!
2. Technical support- We have one group of technical team which can develop and design the product according to the requirements of customers!
3. We have a professional sales team can provide excellent service for you!
