Грузовик с воздушной платформой Marilyn DONGFENG DKL
US $12000-$29900
I-SUZU 18m грузовик с воздушной платформой для продажи по заводской
- Категория: High-altitude Operation Trucks >>>
- Поставщик: Hubei,Hontop,Special,Vehicle,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 41531.46 $* | 43608.30 $* |
| Aug-19-2025 | 41182.63 $* | 43241.66 $* |
| Jul-19-2025 | 34551.54 $* | 36279.53 $* |
| Jun-19-2025 | 40484.34 $* | 42508.37 $* |
| May-19-2025 | 35249.58 $* | 37011.74 $* |
| Apr-19-2025 | 39786.86 $* | 41775.61 $* |
| Mar-19-2025 | 39437.78 $* | 41409.46 $* |
| Feb-19-2025 | 39088.4 $* | 41042.43 $* |
| Jan-19-2025 | 38739.52 $* | 40676.62 $* |
Характеристики
Isuzu 18m aerial working vehicle main performance parameters:
Maximum operating height: 18m maximum operating range: 7.5m
The international leading qingling high-grade chassis with three folding arm hydraulic lifting special device
Painted green items to national motor vehicle the fifth stage emission standard Ⅴ (countries)
★ domestic, imported reversing valve and hydraulic cylinder, stable, flexible and convenient operation, the hydraulic system to
achieve the upper and lower vehicle interlock, overload protection, cylinder safety self-lock, the system with overload protection
valve, oil pressure over the fixed value, automatic unloading
★ turntable, work bucket double station operation
★ boom structure compact, good mobility, large operating range
★ legs and working arm interlock, safe and reliable, prevent misoperation
★ h-type support leg, span large, good stability, support leg can be independently telescopic, but also linkage, equipped with the
support leg flashing light, for the operation of the support leg outline, light alarm signal
Work bucket automatic leveling, external pull rod forced balance
● optional 1 ton hook (hook extension 800-1000mm)
● optional automatic protection system to prevent misoperation
● optional emergency power source, can achieve emergency car collection
● optional electro-hydraulic proportional speed control system, stepless speed control, smooth operation/electronic control system
can be optional ground wireless remote control operating system
The international leading qingling high-grade chassis with three folding arm hydraulic lifting special device
Painted green items to national motor vehicle the fifth stage emission standard Ⅴ (countries)
★ domestic, imported reversing valve and hydraulic cylinder, stable, flexible and convenient operation, the hydraulic system to
achieve the upper and lower vehicle interlock, overload protection, cylinder safety self-lock, the system with overload protection
valve, oil pressure over the fixed value, automatic unloading
★ turntable, work bucket double station operation
★ boom structure compact, good mobility, large operating range
★ legs and working arm interlock, safe and reliable, prevent misoperation
★ h-type support leg, span large, good stability, support leg can be independently telescopic, but also linkage, equipped with the
support leg flashing light, for the operation of the support leg outline, light alarm signal
Work bucket automatic leveling, external pull rod forced balance
● optional 1 ton hook (hook extension 800-1000mm)
● optional automatic protection system to prevent misoperation
● optional emergency power source, can achieve emergency car collection
● optional electro-hydraulic proportional speed control system, stepless speed control, smooth operation/electronic control system
can be optional ground wireless remote control operating system
Technical Data | ||||
General | Chassis type | QL1070A1KWY | ||
Dimension | 8380*2320*3500 | |||
Gross weight | 6810 kg | |||
Wheelbase | 3815 | |||
Emission standard | Euro 4 | |||
Superstructure Specification | ||||
Arm | Max working height | 18 m | ||
Arm Material/thickness | Strengthen Steel Plate Q345B/4mm | |||
Boom section | Quadrilateral | |||
Arm form | 3 folding arm | |||
Operation | Working height at maximum working radium | 18 m | ||
Working radium at maximum working height | 1.6 m | |||
maximum working radium | 10.4 m | |||
Rotation angle | 360° continuous rotation | |||
Landing leg | Material | HQ60/5mm | ||
Leg span | Longitudinal (mm) : 4650（4160）, transverse (mm) : 3900 | |||
Hydraulic lock | 2 Hydraulic lock | |||
Bucket | Rated load capacity | ≤200 Kg | ||
Dimension | 1080*620*1150 mm | |||
Leveling form | External pull rod mechanical leveling | |||
Safety belt | 1 | |||
