VSS Mobile 1080P 8MP Onvif CCTV IP-камера безопасности 16CH NVR Поддержка 16PCS

VSS Mobile 1080P 8MP Onvif CCTV IP-камера безопасности 16CH NVR Поддержка 16PCS

Категория: Системы CCTV >>>
Поставщик: Shenzhen,Unicon,Vision,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.62 $*	0.20 $*
Aug-16-2025	0.95 $*	0.96 $*
Jul-16-2025	0.50 $*	0.34 $*
Jun-16-2025	0.90 $*	0.35 $*
May-16-2025	0.2 $*	0.38 $*
Apr-16-2025	0.23 $*	0.10 $*
Mar-16-2025	0.39 $*	0.43 $*
Feb-16-2025	0.63 $*	0.19 $*
Jan-16-2025	0.31 $*	0.35 $*

Характеристики

Product Description

VSS Mobile 1080P 8MP Onvif CCTV IP Camera Security 16CH NVR Support 16PCS HDD

Key Features:

16CH H.265 1080P POE NVR system
16ch 1080p@30fps(8Mbps) video input
16ch 1080P real time Playback
Support 16 SATA interface(Max 10TB)
1 RJ45 10M / 100M adaptive Ethernet interface
Two-way voice intercom,small size: 215x235x50mm * With 4pcs internet cable: 20m*2psc ; 30m*2pcs

Specification :

OS			Embedded Linux
master chip			Hi3535
Access Bandwidth			128M
Video&Audio input	Bidirectional Talk		1CH,BNC(Line in,2Vp-p,1Kohms)
	IPC Input		up to 16ch 1080P/3MP/4MP/5MP
Video&Audio output	CVBS Output		1CH,BNC(1.0Vp-p,75ohms)
	VGA		1CH,Resolution 1920×1080,1280×1024, 1280×720,1024×768,800×600
	HDMI		Standard 1.3a
			Resolution 1920×1080, 1280×1024,1280×720,1024×768,800×600
	Audio Output		1CH,BNC(Line out,2Vpp,300ohms)
Video&Audio encoding	Audio Compression		G711A
	Audio Bit Rate		64Kbps
Video&Audio decoding	IP Resolution		Main stream:up to 5632x4224 Sub stream: no more than D1
	Video bitrate		2Mbps/D1, 4Mbps/720P, 8Mbps/1080P
	Video decoding		MPEG-4/H.264 High Profil/level4.2
	Synchronous Playback		Up to 16CH
Elligent Analysis		N/A
resource capacity	Play back		6CH 1080P real time/4CH 3MP@25fps/3CH 4MP@25fps/2CH 5MP@25fps playback
Other Function	Bidirectional Talk		Two-way voice intercom function
	Motion Detection		Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest)
	Picture Capture		Local Capture&Web Capture
HDD Interface	SATA		8 SATA Interfaces
	ESATA		1 ESATA Interfaces
External Interface	Network Interface		2 RJ45 10M/100M/1000M adaptive Ethernet interface
	USB		2 USB 2.0 Interfaces
	POE port		N/A
	Alarm		16ch input / 4ch output
	RS-232		1RS-232 interface
	RS-485		1RS-485 interface
General	Dimensions		440x450x90mm(W×D×H)
	Weight		7Kg(without HDD)
	Power Supply		110V~220V±10%, 47Hz~63Hz
	Working Temperature		-10℃--+55℃
	Working Humidity		10%--90%
	Consumption		20W(without HDD)
