Italian Brand Heavy Oil Lpg Diesel CNG Burner For Industrial Boiler
Product Description
Full Premixed Combustion Technology
Full premixed combustion, which belongs to surface burning. gas and air, pre-mixed before entering the burner. the shape of the burner head is a metal cylinder. the wire mesh (made of special alloy) made by Riello's patented “seamless weaving thread” is wrapped on the surface of the metal cylinder. full premixed combustion, the flame is only produced on the surface of the burner, and the actual size of the flame is the same as the size of the burner head. therefore, the full premix burner does not require a large furnace size and still achieves perfect combustion in a small furnace.
When the surface of the metal fiber is burned, the combustion is uniform, a local high temperature region cannot be formed, and the temperature of the flame surface is relatively low, therefore, the generation of NOx is suppressed. In addition, the burning rate is very fast, the flame is very short, and the residence time of the combustion products is very short. therefore, the opportunity for NOx generation is also suppressed.
PREMIX series of full premix burners, NOx emissions can reach the lowest 18mg / Nm³.
RX S/PV Series Fan and Brushless Motor
RX S/PV type burner fan adopts brushless motor, which can realize speed adjustment without frequency conversion drive. This type burner power is strong but quiet operation, with small size, low energy consumption and low noise emission.
RX S/E Series LMV37 Digital Burner Management System
Combustion technology is constantly evolving to meet the demands of escalating industrial applications and more stringent regulatory requirements. RX S/E series burners use LMV37 burner management system and independent fuel-air servo motor. user-friendly interface and precise fuel-air ratio control ensure the safety and reliability of the RX S/E Series burners.
Technique Parameters
Output Range
Boiler Model
PREMIX Burner Model
Power (V/Ph/Hz)
Thermal Output (KW)
Less than 0.5 t/h
RX 35 S/PV
1/ 230V/ 50Hz
6 - 30
RX 70 S/PV
1/ 230V/ 50Hz
14 - 70
RX 150 S/PV
1/ 230V/ 50Hz
25 - 145
RX 180 S/PV
1/ 230V/ 50Hz
30 - 180
RX 250 S/PV
1/ 230V/ 50Hz
41 - 250
RX 360 S/PV
1/ 230V/ 50Hz
60 - 360
0.5 t/h
RX 500 S/PV
1/ 230V/ 50Hz
82 - 490
RX 700 S/PV
1/ 230V/ 50Hz
140 - 700
1 t/h
RX 850 S/PV
1/ 230V/ 50Hz
170 - 880
RX 1000 S/PV
3N/ 400V/ 50Hz
180 - 1080
2 t/h
RX 1500 S/PV
3N/ 400V/ 50Hz
190 - 1790
RX 1800 S/PV
3N/ 400V/ 50Hz
220 - 1990
RX 2500 S/PV
3N/ 400V/ 50Hz
500 - 2500
3 t/h
RX 3000 S/PV
3N/ 400V/ 50Hz
600 - 3000
Note:Matching with the boiler model, based on more boiler data, final confirmation of the specific burner model
A2: You need to provide your burner requirements, then contact our customer service online, leave your email address, whatsapp and other contact information, and then our business manager will contact you in time.
Q3: What is the fuel of the burner?
A3: light oil, heavy oil,diesel,natural gas,etc. we have oil and gas dual fuel burner.
