Lowest price  potato chips kettle chips frying machine continuous plantain chips frying machine



The potato chips kettle chips frying machine continuous plantain chips frying machine is widely used for frying various kinds of food. such as potato chips ,kettle chips ,plantain chips and other snacks.The heating method, model and filtering method of residue can be customized according to the production demand.

1.The body and mesh belt of the frying machine are made of 304 stainless steel, which is of high quality, durable and safe. All electric machinery adopt NRV motor with CE certification standard, which has low failure rate, convenient control and high efficiency. Electrical appliances are high-quality electrical appliances with guaranteed quality, stable performance, safety and reliability, and long service life.

2.The heating energy of  the potato chips kettle chips frying machine continuous plantain chips frying machine is gas,The burner adopts the imported Italian Baide  burner, which has high thermal efficiency, fast heating speed and long service life. The heat exchanger is made of boiler special pipeline, adopts advanced seamless welding technology, and has strong resistance to burning. Finally, a 10kg 24-hour pressure test is needed to ensure the safety of the heat exchanger.

3.The mesh belt of the plantain chips is designed with double-layer mesh belt. Food is in the middle of the two-layer mesh belt. The lower mesh belt plays the role of conveying products. The upper mesh belt can control the products in frying oil, avoid floating phenomenon and improve the quality of frying products. The width of the mesh belt and the space between the upper and lower mesh belt can be customized according to the product.

4.The oil temperature of the the potato chips kettle chips frying machine continuous plantain chips frying machine is controlled by automatic temperature control system. The oil temperature can be adjusted  between 0 and 300 degrees Celsius. After setting the required frying temperature, there is no need for manual control. The frying machine automatically opens the heating and insulation state, which reduces the worker's labor and avoids the drawbacks of artificial temperature control.

5.The potato chips kettle chips frying machine continuous plantain chips frying machine adopts oil-water mixed frying technology, which is respectively equipped with oil area and water area, and the temperature is controlled in different areas. The residue produced in the frying process can be discharged through the drain valve at the bottom. One side of the fryer is equipped with  glass windows, which can observe the change of water level at any time.



The continuous frying machine includes:

Number	part	function
1	Feeding inlet	The product enters the frying area through the feeding inlet
2	frying zone	The products are fried in this area.
3	mesh belt	double mesh belt,The lower mesh belt is used to transport the fried products, and the upper mesh belt is used to control the fried products in the frying oil.
4	burn	The burner makes the fuel and air fully burnt, provides heat energy, and heats the frying oil.
5	control cabinet	It adopts button operation, which is easy for workers to manipulate the fryer flexibly.
6	hoisting system	Used for lifting the body and cover of fryer to facilitate cleaning and maintenance of fryer.
7	smoke vent	Discharge the waste smoke produced in the combustion process of natural gas or LPG.
8	lampblack outlet	It can discharge the oil fume in time and effectively to ensure the clean and hygienic frying environment.
9	heat-insulation system	Reducing Heat Loss and Improving Energy Utilization
10	discharging outlet	When the product is fried, the product is transported out from the discharging outlet.



The parameters of the plantain chips frying machine:

Model	JTRL-3500
Material	SUS304
Outline size	3500x1000x2000mm
Mesh belt width	600mm
Size of frying zone	3000x600x300mm
Temperature range	0-300℃(adjustable)
Oil capacity	480L
output	100-300kg/h
Heating energy	Gas,lpg and so on
Burner power	200000kcal







Packaging & Shipping

 Packing:

All the machines which need packaged will be covered by film then put into the export standard wooden case ,use thecystosepiment to prevent breaking on ship.

The wooden case will be fixed inside the container tightly by the rope.

Export standard wooden case will be palleted for easy unloading for customers.

Shipping:

We select derect ship for sending the machines to customers within shortest time as we can.

We will update the shipping information to customers in time.

Our Services

 Pre-sales Service:

Inquiry and consulting support

Sample testing support

View our factory

After-sales Service:

Training how to install the machine,training  how to ues the machine

Engineers available to service machinery overseas

Company Information:



Shannon Jiate Machinery Technology Co., Ltd. Is located in Wangjiatiegou industrial districts of Zhengcheng city in Shandong province.Our company is specialized in Frying Machine,Frying Production Line,Meat Processing Machine,Fruit And Vegetable Processing Machine,Pasteurization Machine,Industrial Cooking Machine and so on.

With the experienced and processional team,we exported our products to many countries and regions all over the world.Our products enjoy a good reputation among our customers.

We welcome customers ,business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.

Some customers coming:

FAQ:

1.Are you a factory or a trading company?
Shandong Jiate Machinery is a frying machine manufacturer. We mainly produce various frying equipment, frying production line, fruit and vegetable processing equipment, low temperature pasteurization equipment and various meat products equipment.

2.How does your factory do regarding quality control?
"Quality is priority?
Company always attach great importance to quality controlling from the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skillful workers care every details in handling the producing and packing processes;
3).Quality Control Department specially responsible for quality checking in each proces

3.Why Choose Stainless Steel 304 Fryer?
Stainless steel SUS304 is a food-grade stainless steel material with international certification standards. It has strong corrosion resistance and high temperature resistance, and will not cause any pollution to food.
