Профессиональное офтальмологическое оборудование кератометр Автоматический

Цена:*

Количество:

Product Description

1. SYSTEM OF VISION MEASURING

It can measure the keratometry and refractometry at the same time.

2. SYSTEM OF OPTICAL MEASURING

The basic curvature measurement of parameters of contact lens.

3. System of Users Setting

Convenient and quick setting.

4. System of Fixation

Automatic colorful vision system making your optical measuring comfortable.

TECHNICAL PARAMETERS

Measurement Mode	Cornea/ Refractometry Measurement Mode	Keratometry/Refractometry
		Mode of Keratometry	Refractometry
		Refractometry Measurement Mode	Keratometry
		Mode of CLBC	Substrate curvature of contact lens
Refractometry	Vertex Distance	0, 10, 12, 13.5, 15mm
		Spherical Degree	-25.00~+22.00D(VD=12mm, 0.12or0.25D )
		Cylinder Degree	0.00~+/-10.00D(0.12 or 0.25D)
		Axial	1~180 °(step 1°)
		Cylinder Symbol	- , + , +/-
		Pupil Distance	10~85mm
		Minimum Pupil Diameter	¢2.0 mm
		Measuring Time	0.07sec
Keratometry	Radius of Curvature	5.0 ~10. 2 mm
		Corneal Refractometry	33.00 ~ 67.50D
		Corneal Astigmatism	0.00 ~ -15.00D ( 0.05/0.12/0.25D )
		Corneal Diameter	2.0 ~ 14.0 mm
Others	Printer	Thermal printer
		Saving Settings	3, 5, 10 Minutes
		Monitors	5.6 inch of TFT monitors
		Power	AC 100 ~ 240V, 50/60HZ/90W
		Size/Weight	248(W ) × 476(D) × 475(H) mm/21kg
		Jaw Panel	Max 55 mm
		Data Output	Rs-232 interface, video output
