110 в 120 220 230 промышленный гибкий Дальний инфракрасный полый керамический нагревательный элемент пластина для пластикового ИК нагревательного

Infrared ceramic heater are efficient, robust heaters which provide long wave infrared radiation. They are used in a diverse range of industrial processes such as heaters for thermoforming, and as heaters for paint curing, printing and drying. They are also used very effectively in infrared outdoor heaters and infrared saunas. Most plastics and many other materials absorb infrared wave best in this range, which makes the ceramic heater the most efficient infrared radiant emitter on the market.

1,Nickel chrome resistance wire(NiCr20/80)
2,  K thermocouple or J thermocouple
4,Heater Voltage: 120V 220V 230V 240V 480V standard
5,Useful wavelength range: 2-10 microns
6,Operating temperature is 300°C to 700°C (572°F - 1292°F)
7,Average Operating Life-Up to 20,000 hrs depending on conditions.
8. Recommended radiation distance from heater is 100 mm to 250 mm.
9,Supplied with 100mm ceramic beaded power leads

With thermocuple , Four lead wire

With thermocouple, Two lead wire
