Система теплого коврика для помещений нано-углеродный Графен с электрическим инфракрасным нагревателем питание от сети постоянного и переменного тока CNT PTC пленка подогрева

Описание и отзывы

Трекер стоимости

Характеристики



Indoor Warm Mat System AC DC Electric Far Infrared Nano Carbon Graphene CNT PTC Underfloor Heating Film Heating Floor

PARAMETERS TABLE

Name	Floor Heating Film	Material	PET  Graphene Carbon
Color	Black	Shape	Square Shape
Thickness	0.3mm	Weight	0.01KG
Size	330*310mm	Voltage	110-220V
Power	25w±10%	Installation Power	60-110W/m2
Insulation Intensity	3750v	Heating Conversion	99.96%
Extension Intensity	20KG	Waterproof Grade	IP67
Insulation Resistance	200mΩ	Max Surface Temperature	60℃
Length of Infrared Ray	3-15μm	Connection Length	310mm - 6200mm
Warranty	10 Years	OEM Order	Acceptable
Eco-Friendly	Yes	Samples	Available
Delivery Time	15 Days	Sample  Lead Time	5-7 Days
Quality	High Quantity, Pass CE/ROHS Certification, More Than 70 Years Life Time
Technology	Apply graphene to the heating slurry of the electric heating film successfully. That increases the power density of the electric heating film and accelerates the thermal response, makes the film thinner and improves the overall performance.
Advantage	1. Automated production with independent R&D patent formulation     2. 26 times for products automated the high standard testing process          3. 29 national patents and 25 professional certifications at home and abroad   4. PTC self temperature limit     5. Thermal conversion efficiency over 99%    6. Low power consumption, heating fastly     7. No noise, no dust, no leakage and waterproof     8. 3-15 μm far-infrared health therapy     9. Grounded permitted

Heating Film is a good heating system.

It is easy to install for a variety of floor coverings, whether concrete, wood or old tile or terrazzo.

It is installed with tile adhesive and has almost no effect on the ground elevation.

Heating Film can also be laid directly on the original ground without the need for other treatment of the original ground.

In addition, the thin, pre-heated layer gives you the desired floor temperature in 20-30 minutes after starting the system, so this fast heating system is the best choice for the home.

Heating Film used for overall heating, comfortable heating, wall heating, Indoor high-level demanding and the second decoration.

Heating Film is divided into single-conductor bathroom floor electric warm feet mat and twin conductor bathroom floor electric warm feet mat.



Follow these steps to ensure a successful Heating Film installation.

Step 1: PLAN LAYOUT

Step 2: TRANSFER LAYOUT TO FLOOR

Step 3: INSTALL SENSOR

Step 4: PREPARE SUBFLOOR SURFACE

Step 5: MEASURE THE RESISTANCE (THE FIRST TIME)

Step 6: BEGIN LAYING THE HEATING FILM

Step 7: MEASURE THE RESISTANCE (THE SECOND TIME)

Step 8: INSTALL FLOOR COVERING

Step 9: MEASURE THE RESISTANCE (THE THIRD TIME)

Step 10: INSTALL THE TILE

Step 11: CONNECT POWER SUPPLY AND THERMOSTAT

Step 12: MEASURE THE RESISTANCE (THE FOURTH TIME)

Step 13: RECORD INFORMATION AND AFFIX LABELS

Step 14: ENJOY THE COMFORT OF HEATING FILM



Applications



Hotels, Schoolrooms & Dormitories

Our underfloor heating film is ideal in these spaces as all rooms can be controlled via one central thermostat.



Offices & Buildings

Improved air quality resulting from our underfloor system means happier and more productive employees. It also makes space for other vital office equipment and machinery.



Restaurants

Indoor heating systems have been proven to improve air quality, reduce moisture levels and limit the spread of bacteria, helping your restaurant meet health and safety requirements.



Kindergarten Schools

Give your kids a healthy and safe environment to play in Our floor heating system avoids risks such as heat burns and tripping accidents. It also saves space giving them more room for their activities.



Hospitals

Our electric Heating film provides better air quality than conventional systems. It has also been scientifically proven to help reduce dust mites and the development of viruses and bacteria.



Founded in 1996, located in Sanshui industrial park, Foshan city, Guangdong Warmtact Electrical Heating Technology Co., Ltd is one of the top professional electrical heating products manufacturers in the world.



Warmtact owns the corn technical patents and world’s leading collecting, testing and automatic production equipment for far-infrared graphene heating products.



Warmtact has more than 20000 square meters garden-like factory, owned 29 technical patents and 25 international certificates, awarded Guangdong Top Brand and National High-tech Enterprises in recent years.



We are specialized in design, manufacture and sales of electric heater, underfloor heating film, pet heating mat, fermentation heating mat, snow melting pad and garden heating products.



Our products have passed CQC/CNAS/IAF/CE/CCC/ROHS/ISO and other authoritative certification at home and abroad successfully, have exported to more than 16 countries, such as Germany, USA, Japan, France, UK, Russia, Netherlands, Switzerland, Korea, Sweden, Denmark, Poland, Australia, Canada, Brazil, Chile and others.
