Holykell Factory HPT604 5V Fuel Tank 3 m Level Sensor

Product Description

HPT604 is a submersible fuel level transducer suitable for fuel level measurement in tanks, vessels and containers. It consists of an imported U.S.A MEAS TE silicone core element encased in all 316 stainless steel, hermetically sealed housing. Professional explosion-proof design make it suitable for fuel level measurement in tanks, vessels and containers. 5-10 years design life, the lifelong maintenance for your project escort!

Why Choose HOLYKELL HPT604 Fuel Level Sensor Seires?

Feature	Advantage	Benefit
The all-welded design,ATEX Explosion protection	“0” leak points and permanent sealing ,common international explosionproof standards	Safty,worldwide application in explosive gases and vapours
Suction oil filter design	4 pore design Anti-blocking Prevent plugging rate increases more than 80%	Simple maintenance ,easy to cleaning and installation
lightning surge reverse protection	short-circuit conditions to protect prevent reverse connection; Instant voltage overload protection	Reliable and longlasting in harsh application
The vent with a filter	breath atmospher and protect moisture enter transducer	without maintenance, even in the most humid environments.
USA TE Chip,Digital PCB board	High accuracy 0.25% Small temperature drift,automatically compensates for changes in barometric pressure	Stability,keep sensor running longer by reducing downtime and maintenance costs
Lowe-Power output signals	Low-power output signals for battery-operated or solar measuring systems available ,lowest power supply is 3.3V	energy-saving and environmental protection
PUR cable	The customized cable has high oil resistance, flame retardant, wear resistance, uv resistance and other properties, and can withstand general mechanical external forces	Special for throw in oil for 10 years ,ensures a long service life, even under the big mechanical loads of installation and continuous use

1. 5-10 years design life, the lifelong maintenance; Import diffusion silicon core body, ≤1 ms response time;Its service life is 2-3 times of similar products.

2. Adopt the military printed-circuit board and wiring, with good electromagnetic compatibility;Anti-interference is enhanced by 300%, the stability is over 10 years.

3. The unique design of 4 hole and The unique filter design, it Can effectively filter out impurities,

prevent blockage, prevent shock; Prevent plugging rate increases more than 80%

4. Automatic temperature compensation, -40 ~ 85℃, auto-correction temperature drift.

5. Five layers of seamless and waterproof dustproof connection design, international level IP68;12 mm waterproof and oil-proof cables, the service life is more than 10 years.

6.Filter cover can be filter <0.6mm impurities Overload above 20bar

7.Professional Explosion-Proof Design

Application

The HPT604 (Fuel level sensor) can be found in diesel fuel tanks, gasoline tanks, DEF applications and other tanks measuring a variety of different liquids, and are highly praised by consumers.

Level Measurement in Bio-Fuels

·Monitoring of Gasoline & Diesel Fuel Tanks

·Level Measurement in Ballast Tanks

·Level Measurement in Oil Tanks

·Monitoring of Contain Coolant for Diesel Engines

·Level Measurement in AdBlue Tanks

·Level Measurement in Kerosene

Our Services

Buying Guides

In order to recommend you the most suitable products and make an accurate quotation,please provide the following information and send it to our sales when you are going to make an inquiry, thanks !

1. What is your medium? Diesel, petrol or others.

2. Working Temperature? -30℃~80℃

3. Level range: 0-1m...500m optional

4. Output signal:4-20mA, 0-5V or others
