165T-31 420mesh Yellow White Polyester monofilament silk screen printing mesh



Technical specifications:

Product Name	165T-31 420mesh Yellow White Polyester monofilament silk screen printing mesh
Mesh count	420 mesh / inch , 165T per cm
Color	White, Yellow
Thread diameter	31 micron
Aperture	23 micron
Thickness	48 micron
Weight	36g/sqm
Width	Max 367cm , other width can be made as your request
Application	For screen printing , filtering etc



Specifications of Yellow White Polyester monofilament silk screen printing mesh

1. Polyester printing mesh weave type: Plain
2. Polyester printing mesh mesh count: 10T~165T mesh/cm (25mesh/inch to 420mesh/inch)
3. Polyester printing mesh thread Diameter: 31-250um
4. Polyester printing mesh mesh Opening: 25-740um



Polyester silk screen printing mesh
Model	Mesh/inch	Aperture (micron)	Thread Dia. (micron)	Open Area (%)
24-100	60	316	100	57
32-55	80	257	55	67
32-100	80	212	100	46
36-90	92	183	90	44
39-55	100	177	55	56
43-80	110	149	80	41
47-55	120	152	55	51
53-55	135	133	55	50
54-64	137	115	64	39
64-64	160	85	64	30
72-48	182	90	48	36
72-55	182	85	55	30
80-48	200	72	48	33
90-48	230	56	48	25
100-40	255	58	40	33
120-31	305	49	31	35
120-34	305	45	34	30
130-34	330	40	34	27
140-31	355	36	31	26
140-34	355	31	34	20
150-34	380	23	34	13
165-31	420	23	31	15
Note:The above theoretic data is for reference only,and thickness tollerance







                 Click Here >>>>> Contact Us To Get More Informations









Pro Quality of 165T-31 420mesh Yellow White Polyester monofilament silk screen printing mesh :



MORE ABOUT SCREEN PRINTING MESH SIZE:
Different mesh sizes are used for different applications in the screen printing process. Mesh size is measured by how many threads of mesh there are crossing per square inch. For instance, a 110 mesh screen has 110 threads crossing per square inch.

The higher the mesh count, the finer the threads and holes are in the screen. The size of the mesh has a lot to do with how detailed your image is and how thick the ink you are using is. If you have an image with extremely high detail, a lower mesh screen won’t hold the high detail. The fine lines or dots in the image will simply fall through the holes in the mesh not giving you a correct representation of what your image should be.

Also if you are using a thinner ink, the ink will also flood through the larger holes and soak onto your shirt or substrate making your image blurry as the ink bleeds. On the other hand, if you are trying to print a thicker ink (such as white) through to high of a mesh screen, barely any ink will print through the mesh.



Defferent material of the screen printing mesh :





      Click Here >>>>> Contact Us To Get More Informations







Application of 165T-31 420mesh Yellow White Polyester monofilament silk screen printing mesh:



Widely used in textile printing, T-shirt Printing, electronic printing, ceramics & glass & metal printing, stained paper printing, label plate printing and advertising printing,ect.

Polyester Meshes for Screen Printing is widely used in electronic printing, circuit board printing, glass printing, CD/DVD printing, ceramic printing, graphic printing, packaging printing, fabric printing, etc.





                    Send Inquiry Here To Get A Smaple!!!
