Многопролетная поликарбонатная листовая теплица для сельского хозяйства с системами выращивания

PC sheet greenhouses are fairly the recent advancement in greenhouses. Polycarbonate panels are very light and strong. It can be manufactured to be completely transparent. Greenhouse's PC sheets are treated to be resistant to the degrading effects of ultraviolet sunlight, which gives it an impressive service life. It holds the perfect balance between glass and plastic film.

Frame:The greenhouse frame is made by the materials of hot dip galvanized steel pipes, connected by screws, bolts or suitable connectors. The roof can be pitched roof (supported by rectangular tubes) or arched roof (supported by circular tubes). The uprights of greenhouse is made by the rectangular tubes.The frame structure is anti-corrosion and high-temperature resistant.

Special design is available according to requirement.

Covering Materials:PC(Poly-carbonate) sheet, hard and durable, anti-ultraviolet, can be available on the roof and the side of greenhouse, thickness of which are, for example, 8mm or 10m,or be made according to requirement.

Optional system:

Ventilation system;

Cooling system;

Shading system;

Heating system;

Light compensating system;

Power distribution system

Ventilation system

The way of opening the top window includes one-side top window drove by rack and pinion, two-sides top window drove by rack and pinion, staggered top window drove by rack and pinion, electric roll top window, side window drove by rack and pinion, electrical roll side window, sliding window and etc.

The rack and pinion system has a number of rack and pinion racks. Under the action of the drive shaft, the greenhouse windows open. Due to conform to the direction of hot air flow, it can conducive to the flow of air and summer cooling and dehumidification. This system can effectively improve the greenhouse ventilation area, reduce costs, applicable to all types of greenhouse. Ventilation rate is up to 27%.

Cooling system

Cooling pad and exhauster cooling system is the most cost-effective cooling system for large-scale production facilities. The system has the advantages of simple equipment, low cost, low energy consumption, significant cooling capacity and reliable operation. The cooling pad and exhauster cooling system consists of specialized paper cooling pad, low pressure and high flow axial fan, water circulation system, and control device. Exhausters were installed on both sides of the gable in the greenhouse or closed houses. When it is working, the negative pressure room caused by exhausters can force the hot air flow outside, water evaporation will absorb a significant amount of latent heat, to achieve reducing indoor temperature and increase the humidity

Shading system

a.    External shading system

The primary function of the system is to cool the heat in summer, the sun would diffuse into the greenhouse to ensure that crops from strong light burns. Due to blocking a significant amount of light into the room, it can effectively reduce the accumulation of heat in the greenhouse, drop 4°C to 6°C of room temperature.

Features:

Anti-ultraviolet, anti-hail, reduce the damage to the top of the greenhouse.

According to the different crops, use different shade curtains to meet the needs of various plants under the sunlight.

In summer, through the shade curtain can efficiently reflect part of the sunlight, drop room temperature 4 to 6 degrees Celsius.

b.Internal Shading/Insulation System

Anti-fog and anti-drip: After close the inner shading system, it will form two separate lower and upper spaces in the greenhouse, this can effectively prevent the formation of the fog in the greenhouse and the dewdrops. To increase the indoor insulation effect, we can use double shade system. The curtain has two types, breathable curtain, and insulated curtain, like waterproof space cotton insulation blanket. According to the need, we choose different light transmission capacity of the shade curtain or insulation curtain.

Energy saving and insulation: In winter and night, it can effectively prevent the heat inside the greenhouse through the radiation or heat exchange spill, thus reducing energy consumption and greenhouse operating costs

Heating system

Our company developed a series of boilers with high-efficiency technology, which uses circular combustion technology to make combustion more thorough, while increasing the heating area of the boiler, produce much hot water in a short of time. The system can control water supply automatically by using microcomputer temperature control technology, free to adjust the water temperature. It will work even better with the plumbing air conditioning. (Energy saving, eco-friendly, healthy)

Power distribution system

SHANDONG FORTUNE AGRO-TEK CO., LTD is a professional greenhouse manufacturer which focus on development, manufacture, sales of agriculture greenhouse, garden greenhouse, hydroponics system products, etc. FORTUNE AGRO-TEK is located in Weifang City, is one of the earliest research and development greenhouse companies in China. WEIFANG HOTSPOT IMP&EXP CO., LTD is a subsidiary company that wholly owned by FORTUNE AGRO-TEK for better services and helping and satisfying our customers' demands. Our research and development team to continuously develop new kinds of science and technology products, to meet the needs of modern greenhouse development.

1.   Are you a trader or manufacture?

     A: We are the biggest greenhosue manufacturer and exporter in China.We have built our

         greenhouse in more than 100 countries all over the world.

     2.   How is the Packing&Shipping?

     A: The delivery period of greenhouse project depends on the greenhouse type, size and inner           configuration etc. and the detailed days should be confirmed after we confirm all the

         information above.We will supply the strongest packing and fastest delivery speed.

3.  How long is your products guarantee?

     A: It is 12 months quality guarantee for the whole greenhouse and its material after the

         delivery and horticulture service after the greenhouse completed.

1.Strong design & installation team -15R & D engineers, 2 senior engineers

We can advice reliable design and supply the engineer for the crroect installation.

2.Complete quality monitoring system

We have strict construction organization, advanced production and installation technology, excellent construction team, strictly in accordance with international standards and technical norms to organize design, production, installation.

3.Personal Custom

All the design will be done according to customers' local climate condition.

4.Credit protection

Trade with us, your money will be safe.
