Прицеп для транспортировки сада ATV 1000
US $750.00-$1000
60 тонн 3 Ось боковой оптом грузовой транспортер смежный
- Категория: Trailers >>>
- Поставщик: Shandong,Winwin,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 15232.36 $* | 15994.8 $* |
| Aug-20-2025 | 15104.80 $* | 15859.30 $* |
| Jul-20-2025 | 12672.52 $* | 13306.35 $* |
| Jun-20-2025 | 14848.8 $* | 15590.24 $* |
| May-20-2025 | 12928.61 $* | 13574.20 $* |
| Apr-20-2025 | 14592.59 $* | 15322.11 $* |
| Mar-20-2025 | 14464.6 $* | 15187.12 $* |
| Feb-20-2025 | 14336.24 $* | 15053.85 $* |
| Jan-20-2025 | 14208.81 $* | 14918.38 $* |
Характеристики
Products Description
Technical advantages of railboard Semi Trailer
2， Products through CAE strength analysis for the overall structure optimization, frame optional with a variety of structures, weight light, high loading rate.
3， The use of customized high-strength steel materials to ensure the quality of raw materials, the vehicle strength is higher, more stable performance.
4， The use of automated advanced production technology and equipment, in the welding strength at the same time to improve the aesthetics of welding.
5， The board adopts automatic welding, the weld is beautiful, does not deform, and ensures the welding strength.
Specifications for 60 Ton 3 axle sidewall bulk cargo transport semi trailer
Any color you choice : Design the size according to customer requirements
The semi-trailer of the column-type semi-trailer is the structure of the railing. Widely used, mainly applicable to medium- and heavy-duty and bulk cargo in long-distance transport, strong applicability, has become the first choice of medium- and
long-distance freight vehicles.
long-distance freight vehicles.
Specifications | ||
Tare Weight | About 6.5— 7.6T | |
Dimension | 8500mm-13000mm*2490mm-2500mm*2860mm-2900mm (Size can be choose freely) | |
Loading Capacity (T) | ≤ 60 T | |
Axle | 13 T/16T, FUWA /BPW /Huajing Brand | |
Rim | 9.00-22.5 8.5-20 | |
Tire | 12.00R22.5/ 315 80R22.5 11.00R20 | |
Suspension | Mechanical suspension (Germany Type or America Type) | |
Or Air suspension (China brand or BPW brand ) | ||
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 | |
King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type | |
Support leg | JOST brand D200T or China brand 28Tons (Double speed) | |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, | |
down plate is 16mm ; Material is Q345B Steel . | ||
Side beam | 16mm or 18mm channel steel ( Material is Q235steel ). | |
Side Wall | 600mm-1500mm ，or can be do box type ,for choose | |
Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber（TKL brand）; Two pieces of 45L air tanks | |
ABS | Optional | |
Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) ,optional | |
Valve | WABCO valve (especial for exporting market) | |
Light | LED light (especial for exporting market) | |
Voltage | 24V | |
Receptacle | 7 ways (7 wire harness) | |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
Shipping Terms: | By bulk cargo carrier, RORO or 40HQ container. | |
Why Choose Us
Product packaging & Shipping
Company Profile
Flat bed Semi Trailer
low bed Semi Trailer
Rear dump Semi Trailer
Container transport semi-trailer
Rollover dump Semi Trailer
Side wall Semi Trailer
Cargo Semi Trailer
Bulk Cement semi trailer
Fuel tanker Semi Trailer
FAQ
