Твердосплавные пластины токарные станки инструменты для
- Категория: Turning Tool >>>
- Поставщик: Zhengzhou,Ruizuan,Diamond,Tool,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.71 $* | 0.13 $* |
| Aug-17-2025 | 0.97 $* | 0.95 $* |
| Jul-17-2025 | 0.97 $* | 0.42 $* |
| Jun-17-2025 | 0.18 $* | 0.37 $* |
| May-17-2025 | 0.14 $* | 0.31 $* |
| Apr-17-2025 | 0.18 $* | 0.16 $* |
| Mar-17-2025 | 0.89 $* | 0.0 $* |
| Feb-17-2025 | 0.17 $* | 0.32 $* |
| Jan-17-2025 | 0.30 $* | 0.6 $* |
Характеристики
Product Description
Carbide Inserts Woodturning Lathes Tools Sharpening
Our company - Zhengzhou Ruizuan Diamond Tool Co., Ltd. developed solid CBN Inserts with different grades for different application. Now we have five grades, RZ905, RZ907, RZ957, RZ900, RZ950. Find below introduction of different grades.
Grades | Application | Hardness HV (Mpa) | Bending strength (Mpa) |
RZ905 | Fit for low speed heavy load rough machining. ●High pyroconductivity, definite impact resistance. ●Fit for rough machining of high-hardness alloy cast iron, gray cast iron, nodular cast iron and other materials. | 3000--3200 | 1100--1300 |
RZ907 | Consider abrasion resistance and tipping resistance, high-speed continuous cutting. ●Fit for rough machining and semi-finishing of high-hardness alloy cast iron, high nickel chromium, high ferrochrome and other materials. ●Fit for rough machining and semi-finishing of gray cast iron and nodular cast iron. | 3200--3400 | 1100--1300 |
RZ957 | Excellent wear resistance and heat resistance, high-speed continuous cutting and milling. ●Fit for semi-finishing and finish machining of alloy cast iron, high nickel chromium, high ferrochrome and other materials. ●Fit for semi-finishing and finish machining of gray cast iron, nodular cast iron, and other materials. | 3300--3500 | 1100--1200 |
RZ900 | Excellent wear resistance, tipping resistance and generality, low-speed interrupted cutting. ●Fit for rough machining of quenching workpieces, such as bearing steel, die steel, gauge steel, tool steel, high-speed steel and other materials. | 3000--3200 | 1100--1300 |
RZ950 | Excellent wear resistance and heat resistance, high-speed continuous cutting and milling. ●Fit for semi-finishing and finish machining of quenching workpieces, such as bearing steel, die steel, gauge steel, tool steel, high-speed steel and other materials. | 3000--3200 | 1100--1200 |
Main Features
1) Longer Life than ceramic inserts and tungsten carbide inserts
2) High efficiency. It cuts metals quicker than ceramic inserts and tungsten carbide inserts
3) Cutting more workpieces in unit work shift
4) Competitive on unit cost
5) High accurancy. Precise cutting your workpiece
Detailed Images
T-LAND CHAMFER
Standard: S02020, S05020
Length x degree: 0.2mm x 20 degree, 0.5mm x 20 degree
Application:
0.2mm x 20 degree is for finish cutting or semi-finish cutting
0.5mm x 20 degree is for rough cutting
ISO inserts
Name: named accordionig to ISO
Types: RNGN, CNGN, DNGN, TNGN, WNGN, SCGN, RCGV, RCGX
Diameter: 9mm, 12mm, 16mm, 20mm, 25mm
Machining parts
Name: Brake Discs, Brake Drums, Engine Cylinder, Gearbox, Bearing
Machinin: FESTO
Original: Germany
Domestic famous engines, strong driving force, low fuel consumption, high economic benefits 12F+4R sliding sleeve shift.
Cutting Materials
Cast Irons, Grey cast irons, Steel, hardened steels, High nickel chromium, high ferrochrome,bearing steel, die steel, gauge steel, tool steel, high-speed steel, HSS steel.
Related Products
Our Service
Pre-Sales Service
* Laser Cutting, laser marking
* Parameter recommending
After-Sales Service
* One Year Quality Assurance
* Adjusting parameter to reach best performance.
Packing & Delivery
Packaging | ||
Size | 100 (L) * 50 (W) * 8mm (D) | |
Weight | 0.1KG | |
Packaging Details | The normal package is Plastic box. Sizes: 100x50x8mm 140x60x10mm | |
Other Packaging | ||
Size | 140 (L) * 60 (W) * 12mm (D) | |
Weight | 1.2 T | |
Packaging Details | Other pakcages are available for non-standard products. | |
