Переключатель противозажигания Flipsky 13s 200A 12 мм защита esc регулятор скорости переключатель для скутера электрического

Specs:

Features:

• High Side Switching -> Much safer to use with multiple ESCs and other devices.


• In-rush current limiting.




• RC delay network restricts inrush current to safe levels.


• dV/dt is ~100V/s (This is considered VERY slow for power electronics. Fast would be 50,000,000V/s). At 6,000 uF output capacitance, this is an inrush current of 600mA.




• Smart Power on/off




• Roll-to-start. Has 12 second blanking timer after turn off. Can still be turned on by switch during this period.


• Auto-turn-off. Will turn off automatically after 20 minutes. The output voltage must vary by at least 500mV within any three second interval to reset the turn-off timer.


• Support momentary push button. Hold for 0.3s to turn on, 1s to turn off. Holding it down will cycle it on then off.




• High power, 150A Continuous.


• Very low idle power draw, ~300uA, will last months on battery.

Wire Connection

Related Products

Patents&Certificates

Packing&Shipping

Company Information

Company Profile

  FLIPSKY Technology Co., Ltd was set up in 2017. It grows up quickly and powerfully. We have our own design team, manufacture team including the workshop, marketing and sales department. FLIPSKY mainly focus on second innovation research and development basing on the latest international electronic intelligence technology, manufactures and sells electronic intelligent control products and peripheral accessories.

  The co-founders of FLIPSKY is a group of passionate and innovative post-80s technology enthusiasts. They have been in the electronics intelligent automation industry for nearly 10 years and are skillful from circuit design to PCB layout, embedded software&hardware development, component selection and performance evaluation, product testing, SMT/DIP production and process quality control. Each process is fully experienced and well performed. In addition, the product mechanical designer is from TTI, who designed the RYOBI Brushless Driver Kits and other well-known products.

  The vision of FLIPSKY is to maximize the use of latest international technology and to change life by it. FLIPSKY's products can be applied in electric skateboards, electric vehicles, scooters, car models, ship models, robots and industrial equipment and other industries.

  We hope that more and more international companies and consumers will truly feel the progress that technological innovation has brought to our lives.

Contact Information

E-mail: flipskytech01(at)outlook.com

Tel.: +86 13925798346/0769 82816997

Wechat:+86 13925798346

FAQ

1.  Q: Can the KV value be customizable?

     A: Yes, and the extra cost is about 5USD per unit.

2.  Q: Can you do the motor without logo?

     A: Yes. Both logo customization or no logo can be acceptable if the order q'ty can fulfill the MOQ.
