SS Sanitary Wine Filter Housing with Three Cartridges for Large Batch Wine Making Plant









1. Mirror Surface Finish Complete Stainless Steel Construction;



2. Easy To Install Design With Sanitary Connections, Easy to Clean;



3. Housings Accommodate From One (1) to Many 10", 20", 30" or 40" Cartridges;



4. Clean-in-Place (CIP) /Steam-in-Place (SIP) Design;





> Water Treatment, RO system;



> Pharmaceuticals, API, Biologics;

> Food and Beverage, Wine, Beer, Mineral Water, Distillation Equipment;

> Paints, Inks Plating Solutions;

> Process Chemicals and Electronics Industry ;









Material:		Housing	Stainless Steel 304 and 316L for Choice
		O-Ring	Silicone, Viton, EPDM, etc
Surface Finish:		Interior/Exterior	Electro polished, Ra≤0.2um
Connections:		Inlet/Outlet	Tri Clamp	1” to 10” Or as your request
			Flange
			Thread
			DIN 11851
		Vent	¼" female
		Drain	1" male or as your request
Lid/Cover Type:		Swing Bolts or Tri Clamp(only for single round)
Length:		5, 10, 20, 30 40 inch
Operating Pressure:		Max. 6 bar(87 psi)
Temperature:		Max. 95 ℃ (sterilization 150 ℃)
Cartridge Adapter:		220(DOE), 222, 226, etc
Cartridge Capacity:		1, 3, 5, 7, 8, 9, 10, 12, 15, 20, 24, 30, 36, 45, etc
