The advantage of the secondary construction column pump is as follows:

(1) 28hp Diesel engine can be used anywhere without voltage limitation , in the case of no power supply also can use,very convenient

(2) It can conveying 60m distance .

(3) Pump light weight, easy to move.

(4) Pump configuration high, full hydraulic operation, stable performance, compact structure, low failure rate, long life.

(5) Pump affordable, micro-mortar pump, micro-fine stone concrete pump, micro-concrete pump three configurations for customers to choose.

(6) The use of piston structure automatic air pressure technology, working pressure, pumping distance, high pumping height



Model	JZ-X15(electric)	JZ-X15(diesel)
Motor power	15KW	28hp
Aggregate diameter	Φ 0.5-3 CM
Delivery distance	Vertical 20m / level 60 m
Maxim delivery capacity	7m ³ / h
Working pressure	15mPa
Dimensions	206 * 78 * 130 cm
Equipment weight	550 kg
Pipe	10m  steel  pipe ,10m  flexible  pipe
