Машина для плазменной резки cnc плазменная

Категория: Плазменная резка с ЧПУ >>>
Поставщик: Jinan,Pshine,Machinery,Equipment,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	0.15 $*	0.67 $*
Aug-20-2025	0.30 $*	0.8 $*
Jul-20-2025	0.24 $*	0.76 $*
Jun-20-2025	0.73 $*	0.41 $*
May-20-2025	0.3 $*	0.40 $*
Apr-20-2025	0.42 $*	0.11 $*
Mar-20-2025	0.9 $*	0.71 $*
Feb-20-2025	0.58 $*	0.73 $*
Jan-20-2025	0.82 $*	0.78 $*

Характеристики

Plazma cutting machine cnc plasma cut

Product Application

Plasma cutting machine can cut all kinds of hard-to-cut metals, especially for non-ferrous metals (stainless steel, aluminium,copper, titanium, nickel);
The plasma cutting machine is widely used in automobiles, locomotives, pressure vessels, chemical machinery,nuclear industry, general machinery, construction machinery, steel structure, ships and other

industries.

cnc cutting machine Plasma Cutters

Feature

1) CNC plasma cutter cutting machine The beam uses light structural design,with good rigidity structure, light deadweight .

2) The gantry structure, Y axis used dual-motor dual-driven system,X,Y,Z axis all use dual-straight rail that make the machine driving smoothly with high-precision.

3) Aiming at cutting three dimension LED character, trough metal panels and floor cutting, the accuracy can reach good indicators.

4) It can apply to iron shee the aluminium sheet, the galvanized sheet, hundred steel plates, metal plates and so on.

5) The numerical control system disposes high, the automatic striking arc, the performance is stable.

6) Support Wentai, Astronautics Haire, ARTCAM softwares, Type3 produce standard G code way document,also can change software to read AUTOCAD softwares produce DXF form documents.

Technical parameter

Product name	Plasma cutting machinePXP1530
Working area	1500*3000mm (1325,1560, 2030, 2040, 2060 optional)
Application	Cutting metal, like stainless steel, carbon steel, iron, aluminum, etc.
Cutting methods	Plasma cutting+ Flame cutting +Drill
Control system	Starfire controlller/ Start controller
Driving system	Leadshine driver & Stepper motor
Guide rail	Linear Sqaure rails
Plasma power supplier	China Huayuan power supplier 63A/100A/120A/160A/200A
Plasma power supplier	US Hypertherm power supplier 45A/65A/85A/105A/125A/200A
Optional part	Rotary added on table side
	Flame cutting head
	Drill head
	Servo motor
	Dust prevented cover
	Water table, etc
