High  Quality   YUHUA  20L  50L   Rotary    Evaporator    Rotavapor



YRE-2020z new floor rotary evaporator, which have large capacity and large diameter rotary evaporator. To increase the evaporation area, the solution was placed in a water bath under reduced pressure and heated while rotating, making the solution highly efficient in diffusion and evaporation. It is widely used in sample concentration, drying, extraction and recovery. Is the chemical industry, medicine, food, environmental protection, institutions of higher learning and scientific research laboratories and industrial and mining units, the ideal equipment for mass production.



1. The rotating sealing assembly is made of the latest foreign PTFE material, which has been processed with special technology to enhance the sealing, corrosion resistance and wear resistance.



2. original PTFE combination valve, arbitrary control of air flow, liquid flow, in the case of non-stop, feed, feed, improve working efficiency.



3. The introduction of foreign advanced transmission system, reasonable structure, smooth speed, no impact, durable, practical. Frequency conversion control system and temperature control system are adopted foreign technology to ensure the accuracy of the instrument.









Host part: the introduction of foreign advanced transmission system, reasonable structure, durable, practical.



Control, temperature: foreign advanced frequency conversion control system, temperature control system, ensure the accuracy of the instrument performance.



Water bath pan: adopt imported stainless steel plate to press once. Vertical, automatic lifting function, smooth speed, no impact.



Condensing pipe: high efficiency, heat-resistant glass, large diameter three reflux spiral condensing structure, increase condensing area, save time and money.



Inlet and outlet combined valve: original PTFE three-way combined valve.Arbitrary control of air flow, liquid flow, in the case of non-stop feeding, feeding, improve work efficiency.



Sealing parts: the latest foreign PTFE materials are selected and treated with special technology to enhance the sealing, corrosion resistance and wear resistance.



Main structure: adopt high quality aluminum alloy and stainless steel material, more perfect and improve the reasonable performance of the instrument.







Evaporating Flask	Volume 20L Hanged heavy caliber 125mm	Heating Kettle	Stainless steel water bath with a lot of stamping
Collection Flask	Volume 10L	Temperature control	Digital display temperature setting 0-99℃
Main engine rotation speed	Rotate seed display 10-120r/min	Lift	0-199mm
Rotating Motor	Three-phase Ac/induction motor 220v single-phase supply 125w	Volt	220V/50Hz  Power 5KW
Condenser Pipe	Vertical, efficient three reflow	Outsize	85*52*160cm































Pre-sale Service:
24 Hours online service for your consult.
Help choose right model, and a series of service, person, advise.
Provide discount for many sets order
Choose payment term you convienent .
Promptly production and delivery, inform you in time.

After sale service:
1 year warranty service and all life maintenance.
Technical  Egineer are avalible  for oversea trainning.
Free change for some parts
Remote control technical consult
Free installation DVD
Maintenance plan
