Полный гидравлический гусеничный бульдозер SD22 для
- Категория: Bulldozers >>>
- Поставщик: Shanghai,Super-Above,Industry,Holdings,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 139825.31 $* | 146816.18 $* |
| Aug-17-2025 | 138650.30 $* | 145583.35 $* |
| Jul-17-2025 | 116325.4 $* | 122141.56 $* |
| Jun-17-2025 | 136300.24 $* | 143115.92 $* |
| May-17-2025 | 118675.49 $* | 124609.59 $* |
| Apr-17-2025 | 133950.53 $* | 140648.99 $* |
| Mar-17-2025 | 132775.39 $* | 139414.11 $* |
| Feb-17-2025 | 131600.58 $* | 138180.29 $* |
| Jan-17-2025 | 130425.4 $* | 136946.64 $* |
Характеристики
Bulldozer
It's applicable for the operations in the regions with low ground pressure requirement, applicable for the bulldozing, digging, landfill, and other bulk material operations on the roads, railways, mines, and airportsand is an essential mechanical machine for the building constructions and water conservancy constructions (such as nationaldefense projects, mine constructions, and urban and rural roads).
TECHNICAL SPECIFICATIONS (SD22)
| Engine | |
| Type | Cummins NT855-C250510 in-line,water cooled ,4-cycle, overhead valve direct injection,turbocharged diesel |
| Rated power | 162kw/1800rpm |
| Cylinder number-bore x stroke | 6- 139.7 x 152.4mm (bore x stroke) |
| Piston displacement | 14.01L |
| Rated fuel consumption | 205g/kW.h |
| Max. Torque | 1030.m/ 1250rpm |
| Undercarriage system | |
| Type | Swing type of sprayed beam, suspended structure of equalizer bar |
| Carry rollers | 2 each side |
| Track rollers | 6 each side |
| Track type | Single-grouser, assembled |
| Width of track shoes | 610mm |
| Pitch | 216mm |
| Hydraulic system | |
| Max. Pressure | 14MPa |
| Pump type | Gear pump |
| Discharge | 262L/min lated revelation |
| Working cylinder x number | 120mm x 2 |
| Power transmitting system | |
| Torque converter | 3-element, 1 stage, 1 phase |
| Transmission | Planetary gear,multi-disc clutch,power shift,forced lubrication |
| Main drive | Spiral bevel gear, splash lubrication,single-stage speed reduction |
| Steering clutch | Wet, Multi-disc, spring loaded, hydraulic separated,hydraulic control |
| Steering brake | Wet, floating band type, foot brake with hydraulic booster |
| Final drive | 2-stage speed reduction of spur gear, splash lubrication |
| Blade | |
| blade type | Straight-tilt |
| Dozing capacity(m3) | 6.4 |
| Blade height x width(mm) | 1315 x 3725 |
| Max. Drop below ground(mm) | 538 |
| Max. Tilt adjustment(mm) | 735 |
| Operating weight(kg) | 2830 |
| Efficiency(m3/h) | 330 |
| TRAVEL SPEED | |||
| Gear | 1st | 2nd | 3rd |
| Foward(km/h) | 0~3.6 | 0~6.5 | 0~11.2 |
| Reverse(km/h) | 0~4.3 | 0~7.7 | 0~13.2 |
• Brand accessories, quality assurance
Super-above provides you with the original brand engine,alternator and other spare parts, the quality is more reliable.
• Best solutions
Super-above will provide you best solutions for spare parts,because we have most experienced technical team and after-sale service team.
Quickly intuitive query by 2D/3D makes sure requested spare parts more accurate.
• 24-hour Service
We understand your needs and difficulties. Hence Super-above after-sales team opened 24-hour service hotline to help you solve any problems.
• The most efficient transport
Super-above maintains good cooperation with DHL, TNT etc.international express company. In case of urgent express, promises sending
out within 48 hours, in the shortest time to reach your side.No matter when and where, no matter what you need
Related Products
Q:What kind of company you are ?
A:We will be your best expert in construction site if you try
Q:When is the delivery time ?
A:We will send the products in 7 working days
Q:Hong long is the warranty time ?
A:1 year
Q:What is the MOQ ?
A:We can accpet small quantity to support
Q:How to support a company as our distributor
A:We will send engineer to teach the local sales person and do bid advertisement for our distributor
