1. Forward Gain and Noise Figure measured with 9 dB input EQ and 0 dB input pad.

2. Distortion performance reference output level is 107 dBµV (1 port, Slope, 9dB @ 862 MHz). Digital refers to 550 MHz to 1.2 GHz loading with QAM carriers at -6 dB relative to analog CW carrier levels.



Table 2. Return Path Specifications



Item	Units	Value
Pass Band	MHz	5 - 65/85/204
Gain	dB	24
Frequency Response	dB	± 0.75
Return Loss	dB	18
RF Test Point	dB	- 20
Noise Figure	dB	≤ 6



Table 3. General Specifications



Item	Units	Value
Power Consumption (High Gain / Low Gain)	W	≤25
Supply Voltage	V AC	26 - 65
RF Connectors	-	F - female, Imperial
Dimensions ( W x H x D)	mm	280 x 200 x 130
Weight	kg	2.8
Water/Dust Ingress Protection Rating	-	IP 67
Operating Temperature	°C	- 40 - + 55
Storage Temperature	°C	- 40 - + 80
Relative Humidity Range	-	5% - 95%

Note:

Unless otherwise noted, all specifications reflect typical performance and are referenced to 20°C.













Features

* Supports 1.2 GHz bandwidth
* On site changing frequency split
* Compact design, small and exquisite
* GaAs technology in use
* Improved ESD and Surge protection
* Low noise figure
* Standard JXP plug-in PADs for all adjustments of attenuation and equalization
* Second output can be selected via splitter or tap
