Прямая продажа с завода онлайн ups 5000va Tower online 5
- Категория: Uninterrupted Power Supply (UPS) >>>
- Поставщик: Must,Energy,(guangdong),Tech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.30 $* | 0.85 $* |
| Aug-16-2025 | 0.66 $* | 0.99 $* |
| Jul-16-2025 | 0.31 $* | 0.37 $* |
| Jun-16-2025 | 0.30 $* | 0.68 $* |
| May-16-2025 | 0.66 $* | 0.53 $* |
| Apr-16-2025 | 0.50 $* | 0.57 $* |
| Mar-16-2025 | 0.62 $* | 0.30 $* |
| Feb-16-2025 | 0.32 $* | 0.31 $* |
| Jan-16-2025 | 0.37 $* | 0.87 $* |
Характеристики
Factory directly online ups 5000va Tower online 5 kva ups
Application
- IT Device
- Data Center
- Telecommunication
- Banking
- Industry
- Commercial Facility
- Medical Equipment
EH9115
| MODEL | G2KS1/1 | G3KS1/1 | G5KS1/1 | G6KS1/1 | G7.5KS1/1 | G10KS1/1 |
|---|---|---|---|---|---|---|
| Rated Power | 1.6Kw | 2.4Kw | 4Kw | 4.8Kw | 6Kw | 8Kw |
| INPUT | ||||||
| Rated Voltage | single phase 220V +-25% or 110V +-25% | |||||
| Frequency | 50 Hz/60Hz+-5%(optional+-10%) | |||||
| Power Factor | 3Kva | 4.5Kva | 7.5Kva | 9Kva | 11.3Kva | 15Kva |
| OUTPUT | ||||||
| Rated Voltage | single phases 220V+-1% | |||||
| Frequency | 50/60Hz+-0.5% (inverted tense) | |||||
| Waveform Distortion | Pure sine wave, distortion .s2.S as with linear loads, while s3 as with non-linear loads | |||||
| Imbalance of parallel | current <5% | |||||
| Overload Capacity | Over load 120% can last 10 minutes, over load 150% can last 60 seconds | |||||
| Wave Crest Coefficient | 5:l | |||||
| BATTERY | ||||||
| Rated Voltage | 192VDC | |||||
| Battery Nos | 12Vdcx 16 nos. | |||||
| Battery Voltage | 12 Vdc (14-18 nos adjustable) | |||||
| Back-up Time | Extra battery (back-up time is determined by battery capacity : | |||||
| Back-up Time for battery built-in type | Battery built-in type, use 12V/7AH VRMF lead acid battery | |||||
| 13 min | 8 min | 6 min | 5min | N/A | ||
| SYSTEM | ||||||
| Transfer Time | AC–battery 0ms ; Inverter–bypass < 2 ms | |||||
| Ingress Protection | IP20 | |||||
| Conversion Efficiency | ≥85%(full loading) | |||||
| Noise | <50 db(l meter) | <53 db(l meter) | ||||
| ENVIRONMENT | ||||||
| Temperature | 0℃-45℃ | |||||
| Humidity | 0 – 95% RH,non-condensing | |||||
| Altitude | ≤ 2000m | |||||
| SIZE | ||||||
| WxDxH (mm) | 260x620x625 | |||||
| WIGHT | ||||||
| N. Weight (kg) | 80/45 | 84/50 | 95/60 | 100/65 | 75 | 80 |
| G. Weight (kg) | 90/55 | 94/60 | 105/70 | 110/75 | 85 | 90 |
