2022 продажи самое лучшее качество экономически эффективные продукты газовая
- Категория: Springs >>>
- Поставщик: Dongguan,City,Zhili,Gas,Spring,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 2.86 $* | 2.24 $* |
| Aug-18-2025 | 2.70 $* | 2.73 $* |
| Jul-18-2025 | 2.15 $* | 2.45 $* |
| Jun-18-2025 | 2.63 $* | 2.29 $* |
| May-18-2025 | 2.87 $* | 2.30 $* |
| Apr-18-2025 | 2.62 $* | 2.0 $* |
| Mar-18-2025 | 2.46 $* | 2.12 $* |
| Feb-18-2025 | 2.47 $* | 2.48 $* |
| Jan-18-2025 | 2.44 $* | 2.11 $* |
Характеристики
Product Information
Calculation of tube length and stroke
L（Total length of fully extended）=A（tube length）+S（Stroke）+18（Length of the piston rod's thread）Computational formula of tube length and stroke: A≥S+80.（As the length of stroke increases, the length of tube will increase.)
F1 Force | Stroke | Surface treatment | Standard of product execution | Service life |
30N-1000N | 30MM-400MM | tube painting, piston rod hard chromium plating\\QPQ. | GB/T 25751-2010 | At least 28000 times |
Attention
Installation instryction and precautions of gas spring.
◆The gas spring piston rod must be installed downwards and cannot inverted. So
as to reduce the friction and ensure the best damping effect and cushion
property.
◆Whether the gas spring can be rightly mouthed mainly depends on the
mounting position; and when the gas spring is closed. It’s axial Line must pass
through the center of members.
◆The gas spring cannot be stressed laterally and is forbidden to be used as a
handle.
◆In order to ensure reliable sealing property. The surface of the piston rod cannot
be damaged and coated with paints, chemical matters and the like. The gas spring
must be painted before being mounted.
◆Do not dissect, bake and collide the gas spring due to high pressure product.
◆Do not rotate the gas spring piston rod leftwards. Rotate rightwards in case of
adjusting the direction of the connector.
◆Ambient temperature：·35·＋60℃（80℃ under the special manufacture).
◆The mounting connection point shall be rotated flexibly without blocking
phenomena.
◆Reasonably select the dimension, properly apply the force, and ensure that the
stroke dimension of the piston rod has an allowance of 10mm.
as to reduce the friction and ensure the best damping effect and cushion
property.
◆Whether the gas spring can be rightly mouthed mainly depends on the
mounting position; and when the gas spring is closed. It’s axial Line must pass
through the center of members.
◆The gas spring cannot be stressed laterally and is forbidden to be used as a
handle.
◆In order to ensure reliable sealing property. The surface of the piston rod cannot
be damaged and coated with paints, chemical matters and the like. The gas spring
must be painted before being mounted.
◆Do not dissect, bake and collide the gas spring due to high pressure product.
◆Do not rotate the gas spring piston rod leftwards. Rotate rightwards in case of
adjusting the direction of the connector.
◆Ambient temperature：·35·＋60℃（80℃ under the special manufacture).
◆The mounting connection point shall be rotated flexibly without blocking
phenomena.
◆Reasonably select the dimension, properly apply the force, and ensure that the
stroke dimension of the piston rod has an allowance of 10mm.
Recommend Products
Packing & Delivery
Package: 2 pcs / PE bag and ≤20KGS.
Delivery: Within 20-30 days after order confirmation.
333
Certifications
Our Service
2. Great pre-sales and aftersales service
3. OEM for purchaser's requirment
3. OEM for purchaser's requirment
Our Company
The main products by Zhili include support rod gas spring series, pulling force gas spring series, damper series and controllable gas spring series, and are all up to GB/T 25751-2010 Industrial Standard. Particularly, the sliding door dampers and the rail damper has few leakage and noise through 100,000-time detection. Therefore, the Company is highly appraised by the Customer in the industry, and can afford to produce the products with different specifications according to the customers' requirements. Welcomed to negotiate and visit our company!
FAQ
Q: Are you trading company or manufacturer?
A: We are factory.Q: How long is your delivery time?
A: 10-40 days, special custom-made will be based on the agreed date.
Q: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge while the cost of freight is on customers' side.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance, balance before shipment.
Attention:
1.The quantity of the sample is limited.
2.All the prices are only for reference. Exact price will be based on the latest quotation.
3.The final interpretation right of this event is reserved by ZhiLi company.
2.All the prices are only for reference. Exact price will be based on the latest quotation.
3.The final interpretation right of this event is reserved by ZhiLi company.
