Surge Protector Class II 385V power supply surge protective devices for protecting electronic equipments from surge



Product description:

For installation at LPZ 0 -1 or higher, protecting low voltage equipment from surge damages. Applied in pluggable SPD Class II (Class C) for TN power supply system. Designed according to IEC 61643-1 / GB 18802.1.

Main character:

1. Small volume, high discharge capacity, pluggable

2. Quick response

3. Double thermal disconnector devices, providing reliable protection.

4. Multifunctional terminal for connecting conductors and busbars

5. Green window will change when fault occurs and also provide remote alarm control contact at the same time.

Parameters:

Type	BT PCM 385 RM/2P
Art.-No.	810 846
Rated voltage (max. continuous voltage)	Uc	385V~ (L-N)
Nominal discharge current (8/20µs)	In	20KA (L-N)
Max. discharge current (8/20µs)	Imax	40kA(L-N)
Voltage protection level	Up	≤1.8kV (L-N)
Response time	tA	≤25ns (L-N)
Max. Back up fuse		125AgL/gG
Operating temperature range	Tu	-40°C...+80°C
Cross-sectional area		1.5mm2 ~ 25mm2 solid/35mm2 flexible
Mounting on		35mm DIN rail
Enclosure material		Purple module & light gray (base) thermoplastic, UL94-V0
Dimension		2 mods
Type of remote signaling capacity		Switching contact
Switching capacity		AC:250V/0.5A;DC:250V/0.1A;125V/0.2A;75V/0.5A
Cross sectional area for remote signaling contact		Max. 1.5mm2 solid/flexible
Test standards		YD/T 1235.1; GB 18802.1; IEC 61643-1
Certification		CE (LVD, EMC)
