Автоматическое выключение UT505A ручной тестер сопротивления

Описание и отзывы

Трекер стоимости

Характеристики

Specifications		Range	UT505A
Insulation resistance (Ω)	50V	50V/100V/250V/500V/1000V	0%~10%
		0.01MΩ~50MΩ	±(3%+5)
	100V	0.01MΩ~100MΩ	±(3%+5)
	250V	0.01MΩ~200MΩ	±(1.5%+5)
	500V	0.01MΩ~500MΩ	±(1.5%+5)
	1000V	0.1MΩ~2000MΩ	±(1.5%+5)
		2GΩ~9.9GΩ	±(10%+3)
		10GΩ~20GΩ	±(20%+10)
	Load current	50V (R=50kΩ) 1mA	0%~10%
		100V (R=100kΩ) 1mA	0%~10%
		250V (R=250kΩ) 1mA	0%~10%
		500V (R=500kΩ) 1mA	0%~10%
		1000V (R=1MΩ) 1mA	0%~10%
	Short circuit current		<2mA
Low resistance (Ω)	0.01Ω~20kΩ (about 5V/>200mA)		±(1.5%+3)
DC voltage (V)	0V~600V		±(2%+3)
AC voltage (V)	0V~600V		±(2%+3)
Features
Display count			6000
Auto range/True RMS			√
Step voltage	10% steps at 50%~120% of range		√
DAR	60s/15s and 60s/30s		√
PI/Timing measurement			√
Auto discharge			√
Analog bar graph			√
Continuity buzzer			√
Comparison measurement			√
Low battery indication			√
General Characterisitics
Power	1.5V battery (LR6) x  6
Display	78mm x 59mm
Product color	Red and grey
Product net weight	630g
Product size	103mm x 225mm x 59mm
Standard accessories	Batteries, test leads, test probes, alligator clips
Standard individual packing	Carrying bag, gift box, English manual
Standard quantity per carton	20pcs
Standard carton measurement	515mm x 380mm x 385mm (0.075 CBM per standard carton)
Standard carton gross weight	20.8kg
Optional accessory	Remote test lead
