Станок для полировки стекла станок
- Категория: >>>
- Поставщик: Liaoda,(LAD),Glass,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 9877.60 $* | 10371.43 $* |
| Aug-17-2025 | 9794.77 $* | 10284.7 $* |
| Jul-17-2025 | 8217.14 $* | 8628.88 $* |
| Jun-17-2025 | 9628.49 $* | 10109.0 $* |
| May-17-2025 | 8383.65 $* | 8802.18 $* |
| Apr-17-2025 | 9462.1 $* | 9935.51 $* |
| Mar-17-2025 | 9379.57 $* | 9848.30 $* |
| Feb-17-2025 | 9296.77 $* | 9761.46 $* |
| Jan-17-2025 | 9213.94 $* | 9674.37 $* |
Характеристики
Product Description
Product Application
YD-EM series glass edging machine is used to process glass straight line edge, with 45 degree arris or angle changing chamfer with the usage of angle changing structure. Rough grinding, exact grinding, polish and both sides miter will be finished in one time processing. The rubber clamp can drive thickness 3-25mm glass.
SPECIFICATIONS FOR GLASS EDGING MACHINE | ||||||
Engine | Engine type 1 for straight line edging | Kw/rpm | 1.5/2840 | |||
Engine type 1 for arris | Kw/rpm | 2.2/1440 | ||||
Buncher | Kw/rpm | 1.1/1720 | ||||
Main performance parameters | Main performance parameters | Control | Manual simple control | |||
Travel speed | (max. & min.) | 0.8-6m | ||||
Total nr. of spindle | pc | 9 | ||||
Details | Min. size of glass | mm | 80×80 | |||
Glass thickness | mm | 3~26 | ||||
Outer dimension | m | 6.5×1.0×2.6 | ||||
Main Features
1) Suitable for flat glass straight edge and 45 degree arris;
2) Rough grinding, fine grinding, polishing are done at one pass;
3) Chain or bearing conveying system, stelpless/frequency speed adjustment for option;
4) Manual, single chip or PLC control system for option.
Certifications
Detailed Images
Machine Parts
Name: Machine crossbeam
Raw material: Cast
Original: China
With Cast crossbeam for machine main part, it will good for machine long time using, more steady, More efficient.
Main Features
Name: Motor/Spindle
Brand: Bright
Original: China
Domestic famous engines, strong driving force, low fuel consumption, high economic benefits.
Machine Parts
Name: Water connection
Raw material: 304 stainless steel
Original: China
With high quality 304 stainless steel, easy to fix, no water leakage, no rust, longer use.
Main Features
Name: Automatic oil pump or manual type for option
Brand: LIANG SHENG
Original: China
Domestic famous oil pump, strong driving force, low fuel consumption, high economic benefits, more convenient.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service big machinery overseas.
Packing & Delivery
Packaging | ||
Size(mm) | 2800 (L) * 1000 (W) * 1400(H) | |
Weight | 2.7 T | |
Packaging Details | The normal package is plastic film, suitable for machines loading into the container by shipping. | |
Packaging | ||
Size(mm) | 3840(L) * 1230 (W) * 1500(H) | |
Weight | 1.2 T | |
Packaging Details | The normal package is plywood. Suitable for machine by LCL(less than container lot). Plywood package free of fumigation. If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
