Китай высокая точность электронный видоискатель края местоположение сенсорный датчик точки конденсации с LED Сигнал CNC 160 мм Край Finder

Overview:
        The probe of the photoelectric edge finder is generally a 10mm steel ball, which is tensioned on the measuring pole of the photoelectric edge finder by a spring. When the workpiece is hit, it can be retracted, and the circuit is turned on to emit an optical signal. The coordinate position of the measured surface can be obtained by the indication of the photoelectric edge finder and the machine coordinate position. With the symmetry of the probe, it is also possible to measure some simple dimensions.
working principle:
      Hold the machine on the machine close to the workpiece to find the exact position and use the photoelectric feedback information to the operator.
Features:
1, no need to rotate measurement
2. Quickly explore the work position.
3. For milling machines, end beds, and other mechanical equipment, it can effectively save the time required to find a position.
4, can be applied to the edge, surface and internal and external diameter of high efficiency measurement.
5. When the steel ball is detached, there is a safety spring that can accurately pull it back to its original position.
6, precision 0.005m / m.
