#414*405 мм H-образный луч в

Описание и отзывы

Трекер стоимости

Характеристики

H BEAM

Size:100mm-700mm

Length:6~12meters



Grade: SS400 Q235

Qaulity:own factory, stable quality

Tolerance: Strictly according to the G/B and JIS standard

Delivery time: within 45 days after receiving the L/C or advanced T/T payment.

Price term: FOB/CIF/ CFR according to clients requirements

Payment terms: 100%Irrevercable L/C at sight or T/T

GB  HN

Height*Width	H	B	T1	T2	r	Unit Weight
175*90	175	90	5	8	8	18
200*100	198	99	4.5	7	8	17.8
200*100	200	100	5.5	8	8	20.9
250*125	248	124	5	8	8	25.1
300*150	298	149	5.5	8	13	32
300*150	300	150	6.5	9	13	36.7
350*175	346	174	6	9	13	41.2
350*175	350	175	7	11	13	49.4
400*150	400	150	8	13	13	55.2
400*200	396	199	7	11	13	56.1
400*200	400	200	8	13	13	55.2
450*150	446	150	7	12	13	52.6
450*150	150	151	8	14	15	60.8
450*200	446	199	8	12	13	65.1
475*150	470	150	7	13	13	56.2
475*150	475	151.5	8.5	15.5	13	67.6
475*150	482	153.5	10.5	19	13	83.5
500*150	492	150	7	12	13	55.1
500*150	500	152	9	16	13	72.4
500*150	504	153	10	18	13	81.1
500*200	496	199	9	14	13	77.9
500*200	500	200	10	16	13	88.1
500*200	506	201	11	19	13	102
550*200	546	199	9	14	13	81.5
550*200	550	200	10	16	13	92
600*200	596	199	10	15	13	92.4
600*200	600	200	11	17	13	103
600*200	606	201	12	20	13	118
625*200	625	198.5	13.5	17.5	13	118
625*200	630	200	15	20	13	133
625*200	638	202	17	24	13	156
650*300	646	299	10	15	13	120
650*300	650	300	11	17	13	134
650*300	656	301	12	20	13	154
700*300	692	300	13	20	18	163
700*300	700	300	13	24	18	182
750*300	734	299	12	16	18	143
750*300	742	300	13	20	18	168
750*300	750	300	13	24	18	187
750*300	758	303	16	28	18	224
800*300	792	300	14	22	18	188
800*300	800	300	14	26	18	207
850*300	834	298	14	19	18	179
850*300	842	299	15	23	18	204
850*300	850	300	16	28	18	229
850*300	858	301	17	31	18	255
900*300	890	299	15	23	18	210
900*300	900	300	16	28	18	240
900*300	912	302	18	34	18	283
1000*300	970	297	16	21	18	217
1000*300	980	298	17	26	18	248
1000*300	990	298	17	31	18	271
1000*300	1000	300	19	36	18	310
1000*300	1008	302	21	40	18	345



                                                                                 Application

           H-beam steel is widely used, mainly for: various civil and industrial building structures;A variety of large-span industrial plants and modern high-rise buildings, especially in areas with frequent seismic activity and under high temperature working conditions;Large Bridges with large carrying capacity, good section stability and large span are required.Heavy equipment;Highways;Ship skeleton;Mine support;Foundation treatment and dyke works;Various machine components.
